Linear Thermal Expansion Coefficient

Linear Thermal Expansion Coefficient Navigation

Lead to Rhodium

By Name

By Symbol

By Number

Element

Click button to see citations

Notes

Lead

25 °C

28.9×10-6 K-1

293 K

29×10-6 K-1

280 K

28.9×10-6 K-1

273 K

28.8×10-6 K-1

260 K

28.5×10-6 K-1

240 K

28.2×10-6 K-1

220 K

27.8×10-6 K-1

200 K

27.5×10-6 K-1

180 K

27.2×10-6 K-1

160 K

26.8×10-6 K-1

140 K

26.3×10-6 K-1

120 K

25.6×10-6 K-1

100 K

25×10-6 K-1

90 K

25×10-6 K-1

80 K

24×10-6 K-1

70 K

24×10-6 K-1

60 K

23×10-6 K-1

50 K

22×10-6 K-1

40 K

20×10-6 K-1

30 K

17×10-6 K-1

20 K

11×10-6 K-1

10 K

3.2×10-6 K-1

5 K

0.3×10-6 K-1

Magnesium

25 °C

24.8×10-6 K-1

293 K

25.4×10-6 K-1

280 K

25.2×10-6 K-1

273 K

25.1×10-6 K-1

260 K

24.8×10-6 K-1

240 K

24.4×10-6 K-1

220 K

23.9×10-6 K-1

200 K

23.2×10-6 K-1

180 K

22.2×10-6 K-1

160 K

21.0×10-6 K-1

140 K

19.4×10-6 K-1

120 K

17.6×10-6 K-1

100 K

15.4×10-6 K-1

90 K

13.9×10-6 K-1

80 K

12.2×10-6 K-1

70 K

10.3×10-6 K-1

60 K

8.1×10-6 K-1

50 K

5.7×10-6 K-1

40 K

3.3×10-6 K-1

30 K

1.4×10-6 K-1

20 K

0.4×10-6 K-1

10 K

0.05×10-6 K-1

Nickel

25 °C

13.4×10-6 K-1

293 K

12.8×10-6 K-1

280 K

12.4×10-6 K-1

273 K

12.3×10-6 K-1

260 K

12.2×10-6 K-1

240 K

11.9×10-6 K-1

220 K

11.5×10-6 K-1

200 K

11.0×10-6 K-1

180 K

10.5×10-6 K-1

160 K

9.8×10-6 K-1

140 K

8.8×10-6 K-1

120 K

7.5×10-6 K-1

100 K

6.1×10-6 K-1

90 K

5.5×10-6 K-1

80 K

4.7×10-6 K-1

70 K

3.8×10-6 K-1

60 K

2.8×10-6 K-1

50 K

1.9×10-6 K-1

40 K

1.0×10-6 K-1

30 K

0.5×10-6 K-1

20 K

0.2×10-6 K-1

Niobium

25 °C

7.3×10-6 K-1

293 K

7.1×10-6 K-1

280 K

6.9×10-6 K-1

273 K

6.9×10-6 K-1

260 K

6.8×10-6 K-1

240 K

6.7×10-6 K-1

220 K

6.6×10-6 K-1

200 K

6.4×10-6 K-1

180 K

6.2×10-6 K-1

160 K

5.9×10-6 K-1

140 K

5.6×10-6 K-1

120 K

5.2×10-6 K-1

100 K

4.7×10-6 K-1

90 K

4.4×10-6 K-1

80 K

4.0×10-6 K-1

70 K

3.6×10-6 K-1

60 K

3.1×10-6 K-1

50 K

2.4×10-6 K-1

40 K

1.7×10-6 K-1

30 K

0.9×10-6 K-1

20 K

0.3×10-6 K-1

Palladium

25 °C

11.8×10-6 K-1

283 K

11.78×10-6 K-1

85 K

7.00×10-6 K-1

75 K

6.21×10-6 K-1

65 K

5.23×10-6 K-1

30 K

1.24×10-6 K-1

28 K

1.05×10-6 K-1

25 K

0.785×10-6 K-1

22 K

0.560×10-6 K-1

20 K

0.435×10-6 K-1

18 K

0.330×10-6 K-1

15 K

0.213×10-6 K-1

12 K

0.126×10-6 K-1

10 K

0.0850×10-6 K-1

8 K

0.0550×10-6 K-1

6 K

0.0335×10-6 K-1

5 K

0.0255×10-6 K-1

4 K

0.0190×10-6 K-1

3 K

0.0135×10-6 K-1

Rhodium

25 °C

8.2×10-6 K-1

283 K

8.45×10-6 K-1

85 K

4.18×10-6 K-1

75 K

3.50×10-6 K-1

65 K

2.77×10-6 K-1

57.5 K

2.23×10-6 K-1

30 K

0.335×10-6 K-1

28 K

0.265×10-6 K-1

25 K

0.181×10-6 K-1

22 K

0.120×10-6 K-1

20 K

0.090×10-6 K-1

18 K

0.068×10-6 K-1

15 K

0.046×10-6 K-1

12 K

0.031×10-6 K-1

10 K

0.023×10-6 K-1

8 K

0.0175×10-6 K-1

6 K

0.0127×10-6 K-1

5 K

0.0106×10-6 K-1

4 K

0.0084×10-6 K-1

3 K

0.0062×10-6 K-1

References (Click the next to a value above to see complete citation information for that entry)

Barron, T. H. K., and G. K. White. Heat Capacity and Thermal Expansion at Low Temperatures. New York: Kluwer Academic / Plenum Publishers, 1999.

Cohen, E. Richard, David R. Lide, and George L. Trigg, editors. AlP Physics Desk Reference, 3rd edition. New York: Springer-Verlag New York, Inc., 2003.

Jensen, J. E., R. B. Stewart, W. A Tuttle, H. Brechna, and A. G. Prodell, editors. Brookhaven National Laboratory Selected Cryogenic Data Notebook. BNL 10200-R, Vol. 1, Brookhaven National Laboratory, August 1980.

Lide, David R., editor. CRC Handbook of Chemistry and Physics, 88th edition. Boca Raton, Florida: Taylor & Francis Group, 2008.

White, G. K., and A. T. Pawlowicz. "Thermal Expansion of Rhodium, Iridium, and Palladium at Low Temperatures." Journal of Low Temperature Physics, volume 2, number 5-6, 1970, pp. 631–639. doi:10.1007/BF00628279
