Rhenium to Scandium

Element

Click button to see citations

Notes

Rhenium

solid

2600 K, polycrystalline

59.2 W/(m K)

2400 K, polycrystalline

56.3 W/(m K)

2200 K, polycrystalline

53.9 W/(m K)

2000 K, polycrystalline

51.9 W/(m K)

1900 K, polycrystalline

50.9 W/(m K)

1800 K, polycrystalline

50.0 W/(m K)

1700 K, polycrystalline

49.2 W/(m K)

1600 K, polycrystalline

48.5 W/(m K)

1500 K, polycrystalline

47.8 W/(m K)

extrapolated or interpolated

1400 K, polycrystalline

47.1 W/(m K)

extrapolated or interpolated

1300 K, polycrystalline

46.4 W/(m K)

extrapolated or interpolated

1200 K, polycrystalline

45.7 W/(m K)

extrapolated or interpolated

1100 K, polycrystalline

45.1 W/(m K)

extrapolated or interpolated

1000 K, polycrystalline

44.6 W/(m K)

extrapolated or interpolated

900 K, polycrystalline

44.3 W/(m K)

extrapolated or interpolated

800 K, polycrystalline

44.1 W/(m K)

extrapolated or interpolated

700 K, polycrystalline

44.0 W/(m K)

extrapolated or interpolated

600 K, polycrystalline

44.2 W/(m K)

extrapolated or interpolated

500 K, polycrystalline

44.9 W/(m K)

400 K, polycrystalline

46.1 W/(m K)

350 K, polycrystalline

47.0 W/(m K)

300 K, polycrystalline

47.9 W/(m K)

298.2 K, polycrystalline

48.0 W/(m K)

273.2 K, polycrystalline

48.6 W/(m K)

250 K, polycrystalline

49.2 W/(m K)

200 K, polycrystalline

51.0 W/(m K)

100 K, polycrystalline

58.9 W/(m K)

80 K, polycrystalline

62.9 W/(m K)

60 K, polycrystalline

77.4 W/(m K)

40 K, polycrystalline

156 W/(m K)

20 K, polycrystalline

11.6×102 W/(m K)

18 K, polycrystalline

15.4×102 W/(m K)

16 K, polycrystalline

20.3×102 W/(m K)

15 K, polycrystalline

23.1×102 W/(m K)

14 K, polycrystalline

26.0×102 W/(m K)

13 K, polycrystalline

28.9×102 W/(m K)

12 K, polycrystalline

31.7×102 W/(m K)

11 K, polycrystalline

34.0×102 W/(m K)

10 K, polycrystalline

35.6×102 W/(m K)

9 K, polycrystalline

36.6×102 W/(m K)

8 K, polycrystalline

36.6×102 W/(m K)

7 K, polycrystalline

35.6×102 W/(m K)

6 K, polycrystalline

33.3×102 W/(m K)

5 K, polycrystalline

29.7×102 W/(m K)

4 K, polycrystalline

25.0×102 W/(m K)

3 K, polycrystalline

19.4×102 W/(m K)

2 K, polycrystalline

13.2×102 W/(m K)

extrapolated or interpolated

1 K, polycrystalline

665 W/(m K)

extrapolated or interpolated

Rhodium

solid

2000 K

112 W/(m K)

1900 K

111 W/(m K)

1800 K

110 W/(m K)

1700 K

110 W/(m K)

1600 K

110 W/(m K)

1500 K

110 W/(m K)

1400 K

112 W/(m K)

extrapolated or interpolated

1300 K

114 W/(m K)

extrapolated or interpolated

1200 K

116 W/(m K)

extrapolated or interpolated

1100 K

118 W/(m K)

extrapolated or interpolated

1000 K

121 W/(m K)

extrapolated or interpolated

900 K

124 W/(m K)

extrapolated or interpolated

800 K

127 W/(m K)

extrapolated or interpolated

700 K

131 W/(m K)

extrapolated or interpolated

600 K

136 W/(m K)

extrapolated or interpolated

500 K

141 W/(m K)

400 K

146 W/(m K)

350 K

148 W/(m K)

300 K

150 W/(m K)

298.2 K

150 W/(m K)

273.2 K

151 W/(m K)

250 K

152 W/(m K)

200 K

154 W/(m K)

150 K

158 W/(m K)

90 K

206 W/(m K)

80 K

238 W/(m K)

70 K

289 W/(m K)

60 K

378 W/(m K)

50 K

570 W/(m K)

40 K

10.2×102 W/(m K)

30 K

21.6×102 W/(m K)

20 K

36.4×102 W/(m K)

18 K

37.3×102 W/(m K)

16 K

37.0×102 W/(m K)

14 K

35.3×102 W/(m K)

12 K

32.1×102 W/(m K)

10 K

27.8×102 W/(m K)

9 K

25.4×102 W/(m K)

8 K

22.8×102 W/(m K)

7 K

20.1×102 W/(m K)

6 K

17.3×102 W/(m K)

5 K

14.5×102 W/(m K)

4 K

11.6×102 W/(m K)

3 K

869 W/(m K)

2 K

581 W/(m K)

1 K

291 W/(m K)

extrapolated or interpolated

Rubidium

liquid

2000 K

2.72 W/(m K)

extrapolated, interpolated, or estimated

1900 K

5.16 W/(m K)

extrapolated, interpolated, or estimated

1800 K

7.30 W/(m K)

extrapolated, interpolated, or estimated

1700 K

9.33 W/(m K)

extrapolated, interpolated, or estimated

1600 K

11.3 W/(m K)

extrapolated, interpolated, or estimated

1500 K

13.2 W/(m K)

extrapolated, interpolated, or estimated

1400 K

15.0 W/(m K)

extrapolated, interpolated, or estimated

1300 K

16.7 W/(m K)

1200 K

18.4 W/(m K)

1100 K

20.1 W/(m K)

1000 K

21.8 W/(m K)

900 K

23.4 W/(m K)

800 K

25.1 W/(m K)

700 K

26.8 W/(m K)

600 K

28.5 W/(m K)

500 K

30.2 W/(m K)

400 K

31.8 W/(m K)

350 K

32.5 W/(m K)

312.04 K

33.3 W/(m K)

solid

312.04 K

58.1 W/(m K)

300 K

58.2 W/(m K)

298.2 K

58.2 W/(m K)

273.2 K

58.3 W/(m K)

extrapolated, interpolated, or estimated

250 K

58.6 W/(m K)

extrapolated, interpolated, or estimated

200 K

58.9 W/(m K)

extrapolated, interpolated, or estimated

150 K

59.4 W/(m K)

extrapolated, interpolated, or estimated

100 K

60.3 W/(m K)

extrapolated, interpolated, or estimated

80 K

61.1 W/(m K)

extrapolated, interpolated, or estimated

60 K

62.0 W/(m K)

40 K

63.5 W/(m K)

20 K

68.5 W/(m K)

18 K

71.0 W/(m K)

16 K

74.6 W/(m K)

14 K

81.0 W/(m K)

12 K

91.9 W/(m K)

10 K

109 W/(m K)

9 K

122 W/(m K)

8 K

138 W/(m K)

7 K

156 W/(m K)

6 K

173 W/(m K)

5 K

188 W/(m K)

4 K

191 W/(m K)

3 K

171 W/(m K)

2 K

127 W/(m K)

1 K

66.3 W/(m K)

extrapolated, interpolated, or estimated

Ruthenium

solid

2500 K, polycrystalline

79.6 W/(m K)

extrapolated

2400 K, polycrystalline

80.3 W/(m K)

extrapolated

2200 K, polycrystalline

82.0 W/(m K)

extrapolated

2000 K, polycrystalline

83.8 W/(m K)

1900 K, polycrystalline

84.8 W/(m K)

1800 K, polycrystalline

85.9 W/(m K)

1700 K, polycrystalline

87.0 W/(m K)

1600 K, polycrystalline

88.2 W/(m K)

1500 K, polycrystalline

89.5 W/(m K)

1400 K, polycrystalline

90.9 W/(m K)

1300 K, polycrystalline

92.3 W/(m K)

1200 K, polycrystalline

93.9 W/(m K)

1100 K, polycrystalline

95.7 W/(m K)

1000 K, polycrystalline

97.6 W/(m K)

900 K, polycrystalline

99.7 W/(m K)

800 K, polycrystalline

102 W/(m K)

700 K, polycrystalline

105 W/(m K)

600 K, polycrystalline

108 W/(m K)

500 K, polycrystalline

111 W/(m K)

400 K, polycrystalline

114 W/(m K)

350 K, polycrystalline

116 W/(m K)

300 K, polycrystalline

117 W/(m K)

298.2 K, polycrystalline

117 W/(m K)

273.2 K, polycrystalline

117 W/(m K)

250 K, polycrystalline

117 W/(m K)

200 K, polycrystalline

118 W/(m K)

150 K, polycrystalline

128 W/(m K)

100 K, polycrystalline

154 W/(m K)

80 K, polycrystalline

186 W/(m K)

60 K, polycrystalline

310 W/(m K)

40 K, polycrystalline

953 W/(m K)

20 K, polycrystalline

22.6×102 W/(m K)

18 K, polycrystalline

22.3×102 W/(m K)

16 K, polycrystalline

21.3×102 W/(m K)

15 K, polycrystalline

20.5×102 W/(m K)

14 K, polycrystalline

19.7×102 W/(m K)

13 K, polycrystalline

18.7×102 W/(m K)

12 K, polycrystalline

17.5×102 W/(m K)

11 K, polycrystalline

16.3×102 W/(m K)

10 K, polycrystalline

15.0×102 W/(m K)

9 K, polycrystalline

13.6×102 W/(m K)

8 K, polycrystalline

12.2×102 W/(m K)

7 K, polycrystalline

10.7×102 W/(m K)

6 K, polycrystalline

923 W/(m K)

5 K, polycrystalline

771 W/(m K)

4 K, polycrystalline

618 W/(m K)

3 K, polycrystalline

464 W/(m K)

2 K, polycrystalline

309 W/(m K)

extrapolated

1 K, polycrystalline

155 W/(m K)

extrapolated

Samarium

solid

600 K, polycrystalline

14.1 W/(m K)

extrapolated

500 K, polycrystalline

13.5 W/(m K)

extrapolated

400 K, polycrystalline

13.3 W/(m K)

350 K, polycrystalline

13.3 W/(m K)

300 K, polycrystalline

13.3 W/(m K)

298.2 K, polycrystalline

13.3 W/(m K)

273.2 K, polycrystalline

13.3 W/(m K)

250 K, polycrystalline

13.2 W/(m K)

223.2 K, polycrystalline

12.4 W/(m K)

200 K, polycrystalline

11.3 W/(m K)

173.2 K, polycrystalline

10.1 W/(m K)

150 K, polycrystalline

9.24 W/(m K)

100 K, polycrystalline

7.35 W/(m K)

80 K, polycrystalline

7.09 W/(m K)

60 K, polycrystalline

7.14 W/(m K)

40 K, polycrystalline

7.54 W/(m K)

20 K, polycrystalline

6.92 W/(m K)

18 K, polycrystalline

6.23 W/(m K)

16 K, polycrystalline

5.80 W/(m K)

15 K, polycrystalline

5.66 W/(m K)

14 K, polycrystalline

5.51 W/(m K)

13 K, polycrystalline

5.42 W/(m K)

12 K, polycrystalline

5.57 W/(m K)

11 K, polycrystalline

5.86 W/(m K)

10 K, polycrystalline

6.07 W/(m K)

9 K, polycrystalline

6.18 W/(m K)

8 K, polycrystalline

6.11 W/(m K)

7 K, polycrystalline

5.91 W/(m K)

6 K, polycrystalline

5.55 W/(m K)

Scandium

solid

300 K, polycrystalline

15.8 W/(m K)

298.2 K, polycrystalline

15.8 W/(m K)

273.2 K, polycrystalline

15.7 W/(m K)

250 K, polycrystalline

15.6 W/(m K)

200 K, polycrystalline

15.3 W/(m K)

150 K, polycrystalline

14.9 W/(m K)

100 K, polycrystalline

14.3 W/(m K)

80 K, polycrystalline

13.9 W/(m K)

60 K, polycrystalline

13.6 W/(m K)

40 K, polycrystalline

13.8 W/(m K)

20 K, polycrystalline

11.7 W/(m K)

18 K, polycrystalline

10.9 W/(m K)

16 K, polycrystalline

10.1 W/(m K)

15 K, polycrystalline

9.60 W/(m K)

14 K, polycrystalline

9.10 W/(m K)

13 K, polycrystalline

8.55 W/(m K)

12 K, polycrystalline

7.97 W/(m K)

11 K, polycrystalline

7.38 W/(m K)

10 K, polycrystalline

6.78 W/(m K)

9 K, polycrystalline

6.12 W/(m K)

8 K, polycrystalline

5.45 W/(m K)

7 K, polycrystalline

4.79 W/(m K)

6 K, polycrystalline

4.12 W/(m K)

5 K, polycrystalline

3.44 W/(m K)

4 K, polycrystalline

2.76 W/(m K)

3 K, polycrystalline

2.08 W/(m K)

2 K, polycrystalline

1.40 W/(m K)

1 K, polycrystalline

0.706 W/(m K)

extrapolated

Reference (Click the next to a value above to see complete citation information for that entry)

Ho, C. Y., R. W. Powell, and P. E. Liley. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 3, supplement 1, 1974, pp. I–1 to I–796.
