Thermal Conductivity

Thermal Conductivity Navigation

By Name

By Symbol

By Number

Lanthanum to Manganese

Element

Click button to see citations

Notes

Lanthanum

solid

1100 K, polycrystalline

23.2 W/(m K)

extrapolated or interpolated

1000 K, polycrystalline

22.9 W/(m K)

extrapolated or interpolated

900 K, polycrystalline

22.2 W/(m K)

extrapolated or interpolated

800 K, polycrystalline

21.1 W/(m K)

extrapolated or interpolated

700 K, polycrystalline

19.6 W/(m K)

extrapolated or interpolated

600 K, polycrystalline

17.9 W/(m K)

extrapolated or interpolated

500 K, polycrystalline

16.2 W/(m K)

extrapolated or interpolated

400 K, polycrystalline

14.9 W/(m K)

350 K, polycrystalline

14.2 W/(m K)

300 K, polycrystalline

13.5 W/(m K)

298.2 K, polycrystalline

13.4 W/(m K)

273.2 K, polycrystalline

13.1 W/(m K)

250 K, polycrystalline

12.7 W/(m K)

200 K, polycrystalline

11.8 W/(m K)

150 K, polycrystalline

10.9 W/(m K)

100 K, polycrystalline

9.78 W/(m K)

80 K, polycrystalline

9.41 W/(m K)

extrapolated or interpolated

60 K, polycrystalline

9.27 W/(m K)

extrapolated or interpolated

40 K, polycrystalline

10.1 W/(m K)

20 K, polycrystalline

16.8 W/(m K)

18 K, polycrystalline

17.9 W/(m K)

16 K, polycrystalline

18.8 W/(m K)

15 K, polycrystalline

19.1 W/(m K)

14 K, polycrystalline

19.2 W/(m K)

13 K, polycrystalline

19.1 W/(m K)

12 K, polycrystalline

18.8 W/(m K)

11 K, polycrystalline

18.3 W/(m K)

10 K, polycrystalline

17.6 W/(m K)

9 K, polycrystalline

16.6 W/(m K)

8 K, polycrystalline

15.4 W/(m K)

7 K, polycrystalline

14.0 W/(m K)

6 K, polycrystalline

12.4 W/(m K)

5 K, polycrystalline

10.7 W/(m K)

4 K, polycrystalline

8.75 W/(m K)

3 K, polycrystalline

6.74 W/(m K)

2 K, polycrystalline

4.68 W/(m K)

1 K, polycrystalline

2.50 W/(m K)

extrapolated or interpolated

Lead

liquid

1000 K

21.5 W/(m K)

900 K

20.5 W/(m K)

800 K

19.2 W/(m K)

700 K

17.5 W/(m K)

600.652 K

15.5 W/(m K)

solid

600.652 K

31.4 W/(m K)

600 K

31.4 W/(m K)

500 K

32.8 W/(m K)

400 K

34.0 W/(m K)

350 K

34.7 W/(m K)

300 K

35.3 W/(m K)

298.2 K

35.3 W/(m K)

273.2 K

35.6 W/(m K)

250 K

36.0 W/(m K)

200 K

36.7 W/(m K)

150 K

37.9 W/(m K)

100 K

39.7 W/(m K)

90 K

40.3 W/(m K)

80 K

40.9 W/(m K)

70 K

41.6 W/(m K)

60 K

42.5 W/(m K)

50 K

43.6 W/(m K)

45 K

44.2 W/(m K)

40 K

45.1 W/(m K)

35 K

46.2 W/(m K)

30 K

47.7 W/(m K)

25 K

50.7 W/(m K)

20 K

59.1 W/(m K)

18 K

66.1 W/(m K)

16 K

77.2 W/(m K)

15 K

84.5 W/(m K)

14 K

94.4 W/(m K)

13 K

107 W/(m K)

12 K

123 W/(m K)

11 K

146 W/(m K)

10 K

178 W/(m K)

9 K

230 W/(m K)

8 K

320 W/(m K)

7 K

486 W/(m K)

6 K

810 W/(m K)

5 K

13.8×102 W/(m K)

4 K

22.2×102 W/(m K)

3 K

35.8×102 W/(m K)

2 K

44.6×102 W/(m K)

1 K

27.9×102 W/(m K)

Lithium

liquid

4150 K

0.2 W/(m K)

extrapolated or estimated

4000 K

8.6 W/(m K)

extrapolated or estimated

3800 K

19.3 W/(m K)

extrapolated or estimated

3600 K

29.3 W/(m K)

extrapolated or estimated

3400 K

38.3 W/(m K)

extrapolated or estimated

3200 K

46.7 W/(m K)

extrapolated or estimated

3000 K

54.3 W/(m K)

extrapolated or estimated

2800 K

60.2 W/(m K)

extrapolated or estimated

2600 K

64.5 W/(m K)

extrapolated or estimated

2400 K

67.6 W/(m K)

extrapolated or estimated

2200 K

69.6 W/(m K)

extrapolated or estimated

2000 K

70.5 W/(m K)

extrapolated or estimated

1900 K

70.7 W/(m K)

extrapolated or estimated

1800 K

70.7 W/(m K)

extrapolated or estimated

1700 K

70.4 W/(m K)

1600 K

69.9 W/(m K)

1500 K

69.1 W/(m K)

1400 K

68.0 W/(m K)

1300 K

66.5 W/(m K)

1200 K

64.7 W/(m K)

1100 K

62.5 W/(m K)

1000 K

60.0 W/(m K)

900 K

57.2 W/(m K)

800 K

54.1 W/(m K)

700 K

50.9 W/(m K)

600 K

47.6 W/(m K)

500 K

44.3 W/(m K)

453.7 K

42.8 W/(m K)

extrapolated or estimated

solid

453.7 K

77.2 W/(m K)

extrapolated or estimated

400 K

80.4 W/(m K)

350 K

82.8 W/(m K)

300 K

84.7 W/(m K)

298.2 K

84.8 W/(m K)

273.2 K

85.9 W/(m K)

250 K

87.1 W/(m K)

200 K

90.1 W/(m K)

150 K

94.9 W/(m K)

100 K

104 W/(m K)

80 K

120 W/(m K)

60 K

175 W/(m K)

40 K

343 W/(m K)

20 K

720 W/(m K)

18 K

739 W/(m K)

16 K

740 W/(m K)

14 K

725 W/(m K)

12 K

682 W/(m K)

10 K

613 W/(m K)

8 K

515 W/(m K)

6 K

386 W/(m K)

4 K

262 W/(m K)

2 K

132 W/(m K)

1 K

65.8 W/(m K)

extrapolated or estimated

Lutetium

solid

300 K

polycrystalline

16.4 W/(m K)

parallel to c-axis

23.2 W/(m K)

perpendicular to c-axis

13.8 W/(m K)

298.2 K

polycrystalline

16.4 W/(m K)

parallel to c-axis

23.2 W/(m K)

perpendicular to c-axis

13.8 W/(m K)

273.2 K

polycrystalline

16.7 W/(m K)

parallel to c-axis

23.6 W/(m K)

perpendicular to c-axis

14.0 W/(m K)

250 K

polycrystalline

17.0 W/(m K)

parallel to c-axis

24.0 W/(m K)

perpendicular to c-axis

14.2 W/(m K)

200 K

polycrystalline

17.5 W/(m K)

parallel to c-axis

24.9 W/(m K)

perpendicular to c-axis

14.6 W/(m K)

150 K

polycrystalline

18.2 W/(m K)

parallel to c-axis

26.0 W/(m K)

perpendicular to c-axis

15.2 W/(m K)

100 K

polycrystalline

19.2 W/(m K)

parallel to c-axis

27.7 W/(m K)

perpendicular to c-axis

16.0 W/(m K)

80 K

polycrystalline

19.7 W/(m K)

parallel to c-axis

28.5 W/(m K)

perpendicular to c-axis

16.3 W/(m K)

60 K

polycrystalline

20.4 W/(m K)

parallel to c-axis

29.6 W/(m K)

perpendicular to c-axis

16.9 W/(m K)

40 K

polycrystalline

21.6 W/(m K)

parallel to c-axis

31.7 W/(m K)

perpendicular to c-axis

17.8 W/(m K)

20 K

polycrystalline

24.5 W/(m K)

parallel to c-axis

40.6 W/(m K)

perpendicular to c-axis

18.8 W/(m K)

18 K

polycrystalline

24.3 W/(m K)

parallel to c-axis

40.8 W/(m K)

perpendicular to c-axis

18.5 W/(m K)

16 K

polycrystalline

23.7 W/(m K)

parallel to c-axis

40.6 W/(m K)

perpendicular to c-axis

17.9 W/(m K)

14 K

polycrystalline

22.9 W/(m K)

parallel to c-axis

39.7 W/(m K)

perpendicular to c-axis

17.1 W/(m K)

12 K

polycrystalline

21.6 W/(m K)

parallel to c-axis

38.3 W/(m K)

perpendicular to c-axis

16.0 W/(m K)

10 K

polycrystalline

19.9 W/(m K)

parallel to c-axis

35.9 W/(m K)

perpendicular to c-axis

14.5 W/(m K)

8 K

polycrystalline

17.3 W/(m K)

parallel to c-axis

32.2 W/(m K)

perpendicular to c-axis

12.4 W/(m K)

6 K

polycrystalline

13.4 W/(m K)

parallel to c-axis

26.2 W/(m K)

extrapolated

perpendicular to c-axis

9.34 W/(m K)

Magnesium

liquid

1200 K

97.8 W/(m K)

extrapolated or estimated

1100 K

91.1 W/(m K)

extrapolated or estimated

1000 K

84.4 W/(m K)

extrapolated or estimated

923.2 K

79.0 W/(m K)

extrapolated or estimated

solid

923.2 K, polycrystalline

145 W/(m K)

extrapolated or estimated

900 K, polycrystalline

145 W/(m K)

extrapolated or estimated

800 K, polycrystalline

146 W/(m K)

extrapolated or estimated

700 K, polycrystalline

147 W/(m K)

600 K, polycrystalline

149 W/(m K)

500 K, polycrystalline

151 W/(m K)

400 K, polycrystalline

153 W/(m K)

350 K, polycrystalline

154 W/(m K)

300 K, polycrystalline

156 W/(m K)

298.2 K, polycrystalline

156 W/(m K)

273.2 K, polycrystalline

157 W/(m K)

250 K, polycrystalline

157 W/(m K)

200 K, polycrystalline

159 W/(m K)

150 K, polycrystalline

161 W/(m K)

100 K, polycrystalline

169 W/(m K)

90 K, polycrystalline

178 W/(m K)

80 K, polycrystalline

202 W/(m K)

70 K, polycrystalline

249 W/(m K)

60 K, polycrystalline

327 W/(m K)

50 K, polycrystalline

465 W/(m K)

40 K, polycrystalline

719 W/(m K)

30 K, polycrystalline

12.9×102 W/(m K)

20 K, polycrystalline

27.2×102 W/(m K)

18 K, polycrystalline

32.2×102 W/(m K)

16 K, polycrystalline

37.9×102 W/(m K)

14 K, polycrystalline

44.4×102 W/(m K)

12 K, polycrystalline

50.9×102 W/(m K)

10 K, polycrystalline

55.8×102 W/(m K)

9 K, polycrystalline

57.0×102 W/(m K)

8 K, polycrystalline

56.7×102 W/(m K)

7 K, polycrystalline

54.7×102 W/(m K)

6 K, polycrystalline

50.8×102 W/(m K)

5 K, polycrystalline

45.0×102 W/(m K)

4 K, polycrystalline

37.6×102 W/(m K)

3 K, polycrystalline

29.0×102 W/(m K)

2 K, polycrystalline

19.6×102 W/(m K)

1 K, polycrystalline

986 W/(m K)

Manganese

solid

300 K

7.82 W/(m K)

extrapolated or interpolated

298.2 K

7.81 W/(m K)

273.2 K

7.68 W/(m K)

extrapolated or interpolated

250 K

7.54 W/(m K)

extrapolated or interpolated

223.2 K

7.35 W/(m K)

extrapolated or interpolated

200 K

7.17 W/(m K)

extrapolated or interpolated

173.2 K

6.91 W/(m K)

extrapolated or interpolated

150 K

6.63 W/(m K)

extrapolated or interpolated

123.2 K

6.24 W/(m K)

extrapolated or interpolated

100 K

5.79 W/(m K)

extrapolated or interpolated

90 K

5.55 W/(m K)

80 K

5.26 W/(m K)

70 K

4.91 W/(m K)

60 K

4.50 W/(m K)

50 K

4.06 W/(m K)

45 K

3.82 W/(m K)

40 K

3.58 W/(m K)

35 K

3.32 W/(m K)

30 K

3.04 W/(m K)

25 K

2.74 W/(m K)

20 K

2.41 W/(m K)

18 K

2.27 W/(m K)

16 K

2.13 W/(m K)

15 K

2.05 W/(m K)

14 K

1.96 W/(m K)

13 K

1.88 W/(m K)

12 K

1.80 W/(m K)

11 K

1.72 W/(m K)

10 K

1.63 W/(m K)

9 K

1.53 W/(m K)

8 K

1.43 W/(m K)

7 K

1.32 W/(m K)

6 K

1.21 W/(m K)

5 K

1.09 W/(m K)

4 K

0.956 W/(m K)

3 K

0.813 W/(m K)

2 K

0.645 W/(m K)

extrapolated or interpolated

Reference (Click the next to a value above to see complete citation information for that entry)

Ho, C. Y., R. W. Powell, and P. E. Liley. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 3, supplement 1, 1974, pp. I–1 to I–796.
