Thermal Conductivity

Thermal Conductivity Navigation

By Name

By Symbol

By Number

Tantalum to Thorium

Element

Click button to see citations

Notes

Tantalum

solid

3200 K

66.6 W/(m K)

3000 K

66.6 W/(m K)

2800 K

66.4 W/(m K)

2600 K

65.9 W/(m K)

2400 K

65.4 W/(m K)

2200 K

64.8 W/(m K)

2000 K

64.1 W/(m K)

1900 K

63.8 W/(m K)

1800 K

63.4 W/(m K)

1700 K

63.0 W/(m K)

1600 K

62.6 W/(m K)

1500 K

62.2 W/(m K)

1400 K

61.8 W/(m K)

1300 K

61.4 W/(m K)

1200 K

61.0 W/(m K)

1100 K

60.6 W/(m K)

1000 K

60.2 W/(m K)

900 K

59.8 W/(m K)

800 K

59.4 W/(m K)

700 K

59.0 W/(m K)

600 K

58.6 W/(m K)

500 K

58.2 W/(m K)

400 K

57.8 W/(m K)

350 K

57.6 W/(m K)

300 K

57.5 W/(m K)

298.2 K

57.5 W/(m K)

273.2 K

57.4 W/(m K)

250 K

57.4 W/(m K)

interpolated

200 K

57.5 W/(m K)

interpolated

150 K

58.0 W/(m K)

interpolated

90 K

59.6 W/(m K)

80 K

60.3 W/(m K)

70 K

61.6 W/(m K)

60 K

65.1 W/(m K)

50 K

72 W/(m K)

40 K

87 W/(m K)

30 K

115 W/(m K)

20 K

142 W/(m K)

18 K

143 W/(m K)

16 K

140 W/(m K)

14 K

133 W/(m K)

12 K

122 W/(m K)

10 K

107 W/(m K)

9 K

97.9 W/(m K)

8 K

88.4 W/(m K)

7 K

78.4 W/(m K)

6 K

67.8 W/(m K)

5 K

56.9 W/(m K)

4 K

45.8 W/(m K)

3 K

34.4 W/(m K)

2 K

23.0 W/(m K)

1 K

11.5 W/(m K)

Technetium

solid

900 K, polycrystalline

53.4 W/(m K)

extrapolated

800 K, polycrystalline

51.9 W/(m K)

700 K, polycrystalline

50.7 W/(m K)

600 K, polycrystalline

49.9 W/(m K)

500 K, polycrystalline

49.8 W/(m K)

400 K, polycrystalline

50.0 W/(m K)

350 K, polycrystalline

50.2 W/(m K)

300 K, polycrystalline

50.7 W/(m K)

298.2 K, polycrystalline

50.7 W/(m K)

273.2 K, polycrystalline

50.9 W/(m K)

extrapolated

Tellurium

liquid

1100 K

7.09 W/(m K)

extrapolated

1000 K

6.51 W/(m K)

900 K

5.54 W/(m K)

800 K

4.24 W/(m K)

722.7 K

2.90 W/(m K)

solid

700 K

parallel to c-axis

2.29 W/(m K)

perpendicular to c-axis

1.41 W/(m K)

600 K

parallel to c-axis

2.34 W/(m K)

perpendicular to c-axis

1.44 W/(m K)

500 K

parallel to c-axis

2.50 W/(m K)

perpendicular to c-axis

1.52 W/(m K)

400 K

parallel to c-axis

2.80 W/(m K)

perpendicular to c-axis

1.68 W/(m K)

350 K

parallel to c-axis

3.04 W/(m K)

perpendicular to c-axis

1.80 W/(m K)

300 K

parallel to c-axis

3.37 W/(m K)

perpendicular to c-axis

1.96 W/(m K)

298.3 K

parallel to c-axis

3.38 W/(m K)

perpendicular to c-axis

1.97 W/(m K)

273.2 K

parallel to c-axis

3.60 W/(m K)

perpendicular to c-axis

2.08 W/(m K)

250 K

parallel to c-axis

3.83 W/(m K)

perpendicular to c-axis

2.21 W/(m K)

200 K

parallel to c-axis

4.55 W/(m K)

perpendicular to c-axis

2.59 W/(m K)

150 K

parallel to c-axis

5.85 W/(m K)

perpendicular to c-axis

3.28 W/(m K)

100 K

parallel to c-axis

9.12 W/(m K)

perpendicular to c-axis

4.84 W/(m K)

80 K

parallel to c-axis

12.2 W/(m K)

perpendicular to c-axis

6.18 W/(m K)

60 K

parallel to c-axis

18.0 W/(m K)

perpendicular to c-axis

8.70 W/(m K)

40 K

parallel to c-axis

32.1 W/(m K)

perpendicular to c-axis

14.8 W/(m K)

20 K

parallel to c-axis

95.0 W/(m K)

perpendicular to c-axis

40.7 W/(m K)

18 K

parallel to c-axis

114 W/(m K)

perpendicular to c-axis

48.2 W/(m K)

16 K

parallel to c-axis

140 W/(m K)

perpendicular to c-axis

58.3 W/(m K)

14 K

parallel to c-axis

177 W/(m K)

perpendicular to c-axis

72.8 W/(m K)

12 K

parallel to c-axis

231 W/(m K)

perpendicular to c-axis

94.3 W/(m K)

10 K

parallel to c-axis

309 W/(m K)

perpendicular to c-axis

130 W/(m K)

8 K

parallel to c-axis

433 W/(m K)

perpendicular to c-axis

191 W/(m K)

6 K

parallel to c-axis

592 W/(m K)

perpendicular to c-axis

256 W/(m K)

4 K

parallel to c-axis

672 W/(m K)

perpendicular to c-axis

250 W/(m K)

2 K

parallel to c-axis

314 W/(m K)

perpendicular to c-axis

90.6 W/(m K)

Terbium

solid

300 K

polycrystalline

11.1 W/(m K)

parallel to c-axis

14.8 W/(m K)

perpendicular to c-axis

9.59 W/(m K)

298.2 K

polycrystalline

11.1 W/(m K)

parallel to c-axis

14.7 W/(m K)

perpendicular to c-axis

9.56 W/(m K)

273.2 K

polycrystalline

10.4 W/(m K)

parallel to c-axis

13.8 W/(m K)

perpendicular to c-axis

9.00 W/(m K)

250 K

polycrystalline

9.79 W/(m K)

parallel to c-axis

13.1 W/(m K)

perpendicular to c-axis

8.46 W/(m K)

200 K

polycrystalline

10.3 W/(m K)

parallel to c-axis

13.2 W/(m K)

perpendicular to c-axis

9.02 W/(m K)

150 K

polycrystalline

11.9 W/(m K)

parallel to c-axis

15.2 W/(m K)

perpendicular to c-axis

10.6 W/(m K)

100 K

polycrystalline

14.2 W/(m K)

parallel to c-axis

17.7 W/(m K)

perpendicular to c-axis

12.7 W/(m K)

80 K

polycrystalline

15.3 W/(m K)

parallel to c-axis

19.0 W/(m K)

perpendicular to c-axis

13.8 W/(m K)

60 K

polycrystalline

16.8 W/(m K)

parallel to c-axis

20.5 W/(m K)

perpendicular to c-axis

15.1 W/(m K)

40 K

polycrystalline

19.1 W/(m K)

parallel to c-axis

23.1 W/(m K)

perpendicular to c-axis

17.4 W/(m K)

20 K

polycrystalline

22.5 W/(m K)

parallel to c-axis

29.4 W/(m K)

perpendicular to c-axis

19.6 W/(m K)

18 K

polycrystalline

22.3 W/(m K)

parallel to c-axis

29.6 W/(m K)

perpendicular to c-axis

19.3 W/(m K)

16 K

polycrystalline

22.0 W/(m K)

parallel to c-axis

29.6 W/(m K)

perpendicular to c-axis

18.9 W/(m K)

14 K

polycrystalline

21.3 W/(m K)

parallel to c-axis

29.2 W/(m K)

perpendicular to c-axis

18.2 W/(m K)

12 K

polycrystalline

20.4 W/(m K)

parallel to c-axis

28.1 W/(m K)

perpendicular to c-axis

17.3 W/(m K)

10 K

polycrystalline

18.9 W/(m K)

parallel to c-axis

26.3 W/(m K)

perpendicular to c-axis

16.0 W/(m K)

8 K

polycrystalline

16.6 W/(m K)

parallel to c-axis

23.1 W/(m K)

perpendicular to c-axis

14.0 W/(m K)

6 K

polycrystalline

13.1 W/(m K)

parallel to c-axis

17.9 W/(m K)

perpendicular to c-axis

11.2 W/(m K)

Thallium

solid

500 K, polycrystalline

42.1 W/(m K)

extrapolated or interpolated

400 K, polycrystalline

43.8 W/(m K)

300 K, polycrystalline

46.1 W/(m K)

298.2 K, polycrystalline

46.1 W/(m K)

273.2 K, polycrystalline

46.9 W/(m K)

250 K, polycrystalline

47.6 W/(m K)

200 K, polycrystalline

49.4 W/(m K)

150 K, polycrystalline

51.9 W/(m K)

100 K, polycrystalline

55.6 W/(m K)

80 K, polycrystalline

57.8 W/(m K)

60 K, polycrystalline

60.7 W/(m K)

extrapolated or interpolated

40 K, polycrystalline

65.0 W/(m K)

extrapolated or interpolated

20 K, polycrystalline

81.1 W/(m K)

18 K, polycrystalline

88.9 W/(m K)

16 K, polycrystalline

100 W/(m K)

15 K, polycrystalline

107 W/(m K)

14 K, polycrystalline

116 W/(m K)

13 K, polycrystalline

127 W/(m K)

12 K, polycrystalline

140 W/(m K)

11 K, polycrystalline

160 W/(m K)

10 K, polycrystalline

187 W/(m K)

9 K, polycrystalline

230 W/(m K)

8 K, polycrystalline

295 W/(m K)

7 K, polycrystalline

404 W/(m K)

6 K, polycrystalline

619 W/(m K)

5 K, polycrystalline

10.2×102 W/(m K)

4 K, polycrystalline

17.6×102 W/(m K)

3 K, polycrystalline

33.2×102 W/(m K)

2 K, polycrystalline

63.4×102 W/(m K)

extrapolated or interpolated

1 K, polycrystalline

82.7×102 W/(m K)

extrapolated or interpolated

Thorium

solid

1300 K

59.0 W/(m K)

1200 K

58.7 W/(m K)

1100 K

58.3 W/(m K)

1000 K

57.8 W/(m K)

900 K

57.3 W/(m K)

800 K

56.9 W/(m K)

700 K

56.4 W/(m K)

600 K

55.8 W/(m K)

500 K

55.1 W/(m K)

400 K

54.5 W/(m K)

350 K

54.2 W/(m K)

300 K

54.0 W/(m K)

298.2 K

54.0 W/(m K)

273.2 K

54.0 W/(m K)

250 K

54.1 W/(m K)

200 K

54.6 W/(m K)

150 K

56.3 W/(m K)

100 K

59.8 W/(m K)

90 K

61.2 W/(m K)

80 K

63.0 W/(m K)

70 K

65.5 W/(m K)

60 K

69.0 W/(m K)

50 K

74.7 W/(m K)

40 K

84.1 W/(m K)

30 K

104 W/(m K)

20 K

170 W/(m K)

18 K

201 W/(m K)

16 K

241 W/(m K)

14 K

296 W/(m K)

12 K

372 W/(m K)

10 K

466 W/(m K)

9 K

502 W/(m K)

8 K

523 W/(m K)

7 K

520 W/(m K)

6 K

491 W/(m K)

5 K

437 W/(m K)

4 K

364 W/(m K)

3 K

278 W/(m K)

2 K

187 W/(m K)

1 K

93.8 W/(m K)

extrapolated

Reference (Click the next to a value above to see complete citation information for that entry)

Ho, C. Y., R. W. Powell, and P. E. Liley. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 3, supplement 1, 1974, pp. I–1 to I–796.
