Element

Click button to see citations

Vanadium

liquid

4000 K

166.8×10-8 Ohm m

3800 K

162.0×10-8 Ohm m

3600 K

157.5×10-8 Ohm m

3400 K

153.3×10-8 Ohm m

3200 K

149.7×10-8 Ohm m

3000 K

146.4×10-8 Ohm m

2800 K

143.3×10-8 Ohm m

2600 K

140.4×10-8 Ohm m

2400 K

137.6×10-8 Ohm m

2202 K

135.1×10-8 Ohm m

solid

2202 K

118.5×10-8 Ohm m

2100 K

114.8×10-8 Ohm m

2000 K

111.0×10-8 Ohm m

1900 K

107.0×10-8 Ohm m

1800 K

102.7×10-8 Ohm m

1700 K

98.3×10-8 Ohm m

1600 K

93.7×10-8 Ohm m

1500 K

89.0×10-8 Ohm m

1400 K

84.2×10-8 Ohm m

1300 K

79.4×10-8 Ohm m

1200 K

74.5×10-8 Ohm m

1100 K

69.7×10-8 Ohm m

1000 K

64.6×10-8 Ohm m

900 K

59.1×10-8 Ohm m

800 K

53.4×10-8 Ohm m

700 K

47.4×10-8 Ohm m

600 K

41.2×10-8 Ohm m

500 K

34.9×10-8 Ohm m

400 K

28.0×10-8 Ohm m

350 K

24.2×10-8 Ohm m

300 K

20.21×10-8 Ohm m

293 K

19.68×10-8 Ohm m

273 K

18.14×10-8 Ohm m

250 K

16.36×10-8 Ohm m

200 K

12.42×10-8 Ohm m

150 K

8.21×10-8 Ohm m

100 K

4.00×10-8 Ohm m

90 K

3.191×10-8 Ohm m

80 K

2.409×10-8 Ohm m

70 K

1.703×10-8 Ohm m

60 K

1.112×10-8 Ohm m

50 K

0.648×10-8 Ohm m

40 K

0.304×10-8 Ohm m

30 K

0.112×10-8 Ohm m

25 K

0.0660×10-8 Ohm m

20 K

0.0391×10-8 Ohm m

15 K

0.0232×10-8 Ohm m

10 K

0.0145×10-8 Ohm m

7 K

0.0117×10-8 Ohm m

4 K

0.0105×10-8 Ohm m

1 K

0.0100×10-8 Ohm m

Ytterbium

solid, 295 K

26.4×10-8 Ohm m

Yttrium

solid, 295 K

58.5×10-8 Ohm m

Zinc

liquid

1600 K

53.09×10-8 Ohm m

1500 K

47.75×10-8 Ohm m

1400 K

43.60×10-8 Ohm m

1300 K

40.51×10-8 Ohm m

1200 K

38.36×10-8 Ohm m

1100 K

37.04×10-8 Ohm m

1050 K

36.64×10-8 Ohm m

1000 K

36.40×10-8 Ohm m

950 K

36.30×10-8 Ohm m

900 K

36.33×10-8 Ohm m

850 K

36.47×10-8 Ohm m

800 K

36.71×10-8 Ohm m

750 K

37.02×10-8 Ohm m

700 K

37.40×10-8 Ohm m

692.73 K

37.46×10-8 Ohm m

solid

692.73 K

16.75×10-8 Ohm m

650 K

15.49×10-8 Ohm m

600 K

14.05×10-8 Ohm m

550 K

12.64×10-8 Ohm m

500 K

11.27×10-8 Ohm m

450 K

9.94×10-8 Ohm m

400 K

8.64×10-8 Ohm m

350 K

7.37×10-8 Ohm m

300 K

6.13×10-8 Ohm m

293 K

5.964×10-8 Ohm m

273 K

5.479×10-8 Ohm m

250 K

4.923×10-8 Ohm m

200 K

3.742×10-8 Ohm m

150 K

2.596×10-8 Ohm m

100 K

1.495×10-8 Ohm m

90 K

1.281×10-8 Ohm m

80 K

1.072×10-8 Ohm m

70 K

0.865×10-8 Ohm m

60 K

0.662×10-8 Ohm m

50 K

0.465×10-8 Ohm m

40 K

0.285×10-8 Ohm m

30 K

0.135×10-8 Ohm m

25 K

0.0774×10-8 Ohm m

20 K

0.0343×10-8 Ohm m

15 K

0.00911×10-8 Ohm m

10 K

0.00125×10-8 Ohm m

7 K

0.000260×10-8 Ohm m

4 K

0.0000723×10-8 Ohm m

1 K

0.000060×10-8 Ohm m

Zirconium

liquid, 2127 K

141.3×10-8 Ohm m

α-zirconium, solid

1137 K

133.4×10-8 Ohm m

1100 K

132.8×10-8 Ohm m

1000 K

129.4×10-8 Ohm m

900 K

123.6×10-8 Ohm m

800 K

115.3×10-8 Ohm m

700 K

104.5×10-8 Ohm m

600 K

91.7×10-8 Ohm m

500 K

76.6×10-8 Ohm m

400 K

60.3×10-8 Ohm m

350 K

51.9×10-8 Ohm m

300 K

43.3×10-8 Ohm m

293 K

42.1×10-8 Ohm m

273 K

38.8×10-8 Ohm m

250 K

34.9×10-8 Ohm m

200 K

26.33×10-8 Ohm m

150 K

17.84×10-8 Ohm m

100 K

9.78×10-8 Ohm m

90 K

8.17×10-8 Ohm m

80 K

6.63×10-8 Ohm m

70 K

5.14×10-8 Ohm m

60 K

3.75×10-8 Ohm m

50 K

2.492×10-8 Ohm m

40 K

1.441×10-8 Ohm m

30 K

0.711×10-8 Ohm m

25 K

0.490×10-8 Ohm m

20 K

0.357×10-8 Ohm m

15 K

0.283×10-8 Ohm m

10 K

0.253×10-8 Ohm m

7 K

0.250×10-8 Ohm m

4 K

0.250×10-8 Ohm m

1 K

0.250×10-8 Ohm m

β-zirconium, solid

2127 K

131.4×10-8 Ohm m

2100 K

131.0×10-8 Ohm m

2000 K

129.3×10-8 Ohm m

1900 K

127.4×10-8 Ohm m

1800 K

125.4×10-8 Ohm m

1700 K

123.5×10-8 Ohm m

1600 K

121.5×10-8 Ohm m

1500 K

119.6×10-8 Ohm m

1400 K

117.3×10-8 Ohm m

1300 K

115.2×10-8 Ohm m

1200 K

112.8×10-8 Ohm m

1150 K

111.7×10-8 Ohm m

1137 K

111.3×10-8 Ohm m

References (Click the next to a value above to see complete citation information for that entry)

Desai, P. D., H. M. James, and C. Y. Ho. "Electrical Resistivity of Vanadium and Zirconium." Journal of Physical and Chemical Reference Data, volume 13, number 4, 1984, pp. 1097–1130.

Desai, P. D., T. K. Chu, H. M. James, and C. Y. Ho. "Electrical Resistivity of Selected Elements." Journal of Physical and Chemical Reference Data, volume 13, number 4, 1984, pp. 1069–1096.

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.
