Electrical Resistivity

Electrical Resistivity Navigation

By Name

By Symbol

By Number

Mercury to Palladium

Element

Click button to see citations

Molybdenum

solid

2894 K

82.73×10-8 Ohm m

2800 K

79.57×10-8 Ohm m

2600 K

72.93×10-8 Ohm m

2400 K

66.40×10-8 Ohm m

2200 K

59.98×10-8 Ohm m

2000 K

53.67×10-8 Ohm m

1900 K

50.56×10-8 Ohm m

1800 K

47.48×10-8 Ohm m

1700 K

44.43×10-8 Ohm m

1600 K

41.41×10-8 Ohm m

1500 K

38.42×10-8 Ohm m

1400 K

35.46×10-8 Ohm m

1300 K

32.54×10-8 Ohm m

1200 K

29.66×10-8 Ohm m

1100 K

26.81×10-8 Ohm m

1000 K

24.00×10-8 Ohm m

900 K

21.23×10-8 Ohm m

800 K

18.50×10-8 Ohm m

700 K

15.81×10-8 Ohm m

600 K

13.17×10-8 Ohm m

500 K

10.57×10-8 Ohm m

400 K

8.02×10-8 Ohm m

350 K

6.76×10-8 Ohm m

300 K

5.52×10-8 Ohm m

293 K

5.34×10-8 Ohm m

273 K

4.85×10-8 Ohm m

250 K

4.282×10-8 Ohm m

200 K

3.131×10-8 Ohm m

150 K

1.989×10-8 Ohm m

100 K

0.858×10-8 Ohm m

90 K

0.658×10-8 Ohm m

80 K

0.481×10-8 Ohm m

70 K

0.330×10-8 Ohm m

60 K

0.206×10-8 Ohm m

50 K

0.1107×10-8 Ohm m

40 K

0.0456×10-8 Ohm m

35 K

0.0248×10-8 Ohm m

30 K

0.0120×10-8 Ohm m

25 K

0.00560×10-8 Ohm m

20 K

0.00258×10-8 Ohm m

15 K

0.00133×10-8 Ohm m

10 K

0.00088×10-8 Ohm m

7 K

0.00078×10-8 Ohm m

4 K

0.00072×10-8 Ohm m

1 K

0.00070×10-8 Ohm m

Nickel

liquid

2000 K

85.22×10-8 Ohm m

1729 K

82.24×10-8 Ohm m

solid

1728 K

60.22×10-8 Ohm m

1600 K

56.94×10-8 Ohm m

1400 K

51.73×10-8 Ohm m

1200 K

46.62×10-8 Ohm m

1000 K

41.41×10-8 Ohm m

900 K

38.58×10-8 Ohm m

800 K

35.52×10-8 Ohm m

700 K

32.14×10-8 Ohm m

600 K

25.54×10-8 Ohm m

500 K

17.67×10-8 Ohm m

400 K

11.78×10-8 Ohm m

350 K

9.34×10-8 Ohm m

300 K

7.20×10-8 Ohm m

293 K

6.93×10-8 Ohm m

273 K

6.16×10-8 Ohm m

250 K

5.32×10-8 Ohm m

200 K

3.67×10-8 Ohm m

150 K

2.21×10-8 Ohm m

100 K

0.959×10-8 Ohm m

90 K

0.741×10-8 Ohm m

80 K

0.545×10-8 Ohm m

70 K

0.377×10-8 Ohm m

60 K

0.242×10-8 Ohm m

50 K

0.135×10-8 Ohm m

40 K

0.0678×10-8 Ohm m

30 K

0.0317×10-8 Ohm m

25 K

0.0212×10-8 Ohm m

20 K

0.0140×10-8 Ohm m

15 K

0.00901×10-8 Ohm m

10 K

0.00573×10-8 Ohm m

7 K

0.00443×10-8 Ohm m

4 K

0.00360×10-8 Ohm m

1 K

0.00320×10-8 Ohm m

Palladium

liquid

2019 K

83×10-8 Ohm m

2000 K

83×10-8 Ohm m

1900 K

83×10-8 Ohm m

1827 K

83×10-8 Ohm m

solid

1827 K

46.29×10-8 Ohm m

1800 K

46.01×10-8 Ohm m

1700 K

44.88×10-8 Ohm m

1600 K

43.57×10-8 Ohm m

1500 K

42.10×10-8 Ohm m

1400 K

40.46×10-8 Ohm m

1300 K

38.66×10-8 Ohm m

1200 K

36.68×10-8 Ohm m

1100 K

34.54×10-8 Ohm m

1000 K

32.23×10-8 Ohm m

900 K

29.74×10-8 Ohm m

800 K

27.07×10-8 Ohm m

700 K

24.23×10-8 Ohm m

600 K

21.18×10-8 Ohm m

500 K

17.94×10-8 Ohm m

400 K

14.48×10-8 Ohm m

350 K

12.67×10-8 Ohm m

300 K

10.80×10-8 Ohm m

293 K

10.54×10-8 Ohm m

273.15 K

9.78×10-8 Ohm m

250 K

8.88×10-8 Ohm m

225 K

7.89×10-8 Ohm m

200 K

6.88×10-8 Ohm m

175 K

5.85×10-8 Ohm m

150 K

4.80×10-8 Ohm m

125 K

3.73×10-8 Ohm m

100 K

2.62×10-8 Ohm m

90 K

2.19×10-8 Ohm m

80 K

1.75×10-8 Ohm m

70 K

1.32×10-8 Ohm m

60 K

0.938×10-8 Ohm m

55 K

0.765×10-8 Ohm m

50 K

0.606×10-8 Ohm m

45 K

0.460×10-8 Ohm m

40 K

0.334×10-8 Ohm m

35 K

0.230×10-8 Ohm m

30 K

0.150×10-8 Ohm m

25 K

0.0936×10-8 Ohm m

20 K

0.0563×10-8 Ohm m

15 K

0.0345×10-8 Ohm m

10 K

0.0242×10-8 Ohm m

7 K

0.0217×10-8 Ohm m

4 K

0.0205×10-8 Ohm m

1 K

0.0200×10-8 Ohm m

References (Click the next to a value above to see complete citation information for that entry)

Desai, P. D., T. K. Chu, H. M. James, and C. Y. Ho. "Electrical Resistivity of Selected Elements." Journal of Physical and Chemical Reference Data, volume 13, number 4, 1984, pp. 1069–1096.

Ho, C. Y., M. W. Ackerman, K. Y. Wu, T. N. Havill, R. H. Bogaard, R. A. Matula, S. G. Oh, and H. M. James. "Electrical Resistivity of Ten Selected Binary Alloy Systems." Journal of Physical and Chemical Reference Data, volume 12, number 2, 1983, pp. 183–322.

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.

Matula, R. A. "Electrical Resistivity of Copper, Gold, Palladium, and Silver." Journal of Physical and Chemical Reference Data, volume 8, number 4, 1979, pp. 1147–1298.
