Element

Click button to see citations

Beryllium

solid

1500 K, polycrystalline

49.9×10-8 Ohm m

1400 K, polycrystalline

44.8×10-8 Ohm m

1300 K, polycrystalline

40.1×10-8 Ohm m

1200 K

perpendicular to c-axis

31.5×10-8 Ohm m

parallel to c-axis

43.3×10-8 Ohm m

polycrystalline

35.7×10-8 Ohm m

1100 K

perpendicular to c-axis

27.8×10-8 Ohm m

parallel to c-axis

38.3×10-8 Ohm m

polycrystalline

31.5×10-8 Ohm m

1000 K

perpendicular to c-axis

24.4×10-8 Ohm m

parallel to c-axis

33.5×10-8 Ohm m

polycrystalline

27.5×10-8 Ohm m

900 K

perpendicular to c-axis

21.1×10-8 Ohm m

parallel to c-axis

28.9×10-8 Ohm m

polycrystalline

23.7×10-8 Ohm m

800 K

perpendicular to c-axis

17.9×10-8 Ohm m

parallel to c-axis

24.5×10-8 Ohm m

polycrystalline

20.0×10-8 Ohm m

700 K

perpendicular to c-axis

14.8×10-8 Ohm m

parallel to c-axis

20.2×10-8 Ohm m

polycrystalline

16.5×10-8 Ohm m

600 K

perpendicular to c-axis

11.8×10-8 Ohm m

parallel to c-axis

16.0×10-8 Ohm m

polycrystalline

13.2×10-8 Ohm m

500 K

perpendicular to c-axis

8.91×10-8 Ohm m

parallel to c-axis

12.0×10-8 Ohm m

polycrystalline

9.94×10-8 Ohm m

400 K

perpendicular to c-axis

6.08×10-8 Ohm m

parallel to c-axis

8.07×10-8 Ohm m

polycrystalline

6.76×10-8 Ohm m

300 K

perpendicular to c-axis

3.38×10-8 Ohm m

parallel to c-axis

4.43×10-8 Ohm m

polycrystalline

3.76×10-8 Ohm m

293 K

perpendicular to c-axis

3.21×10-8 Ohm m

parallel to c-axis

4.19×10-8 Ohm m

polycrystalline

3.56×10-8 Ohm m

273.15 K

perpendicular to c-axis

2.72×10-8 Ohm m

parallel to c-axis

3.54×10-8 Ohm m

polycrystalline

3.02×10-8 Ohm m

250 K

perpendicular to c-axis

2.18×10-8 Ohm m

parallel to c-axis

2.82×10-8 Ohm m

polycrystalline

2.42×10-8 Ohm m

200 K

perpendicular to c-axis

1.16×10-8 Ohm m

parallel to c-axis

1.48×10-8 Ohm m

polycrystalline

1.29×10-8 Ohm m

150 K

perpendicular to c-axis

0.447×10-8 Ohm m

parallel to c-axis

0.550×10-8 Ohm m

polycrystalline

0.510×10-8 Ohm m

100 K

perpendicular to c-axis

0.103×10-8 Ohm m

parallel to c-axis

0.111×10-8 Ohm m

polycrystalline

0.133×10-8 Ohm m

90 K

perpendicular to c-axis

0.0711×10-8 Ohm m

parallel to c-axis

0.0736×10-8 Ohm m

polycrystalline

0.0989×10-8 Ohm m

80 K

perpendicular to c-axis

0.0483×10-8 Ohm m

parallel to c-axis

0.0471×10-8 Ohm m

polycrystalline

0.0748×10-8 Ohm m

70 K

perpendicular to c-axis

0.0325×10-8 Ohm m

parallel to c-axis

0.0293×10-8 Ohm m

polycrystalline

0.0584×10-8 Ohm m

60 K

perpendicular to c-axis

0.0218×10-8 Ohm m

parallel to c-axis

0.0180×10-8 Ohm m

polycrystalline

0.0675×10-8 Ohm m

50 K

perpendicular to c-axis

0.0150×10-8 Ohm m

parallel to c-axis

0.0112×10-8 Ohm m

polycrystalline

0.0407×10-8 Ohm m

40 K

perpendicular to c-axis

0.0109×10-8 Ohm m

parallel to c-axis

0.0074×10-8 Ohm m

polycrystalline

0.0367×10-8 Ohm m

30 K

perpendicular to c-axis

0.0086×10-8 Ohm m

parallel to c-axis

0.0054×10-8 Ohm m

polycrystalline

0.0345×10-8 Ohm m

20 K

perpendicular to c-axis

0.0076×10-8 Ohm m

parallel to c-axis

0.0046×10-8 Ohm m

polycrystalline

0.0336×10-8 Ohm m

10 K

perpendicular to c-axis

0.0072×10-8 Ohm m

parallel to c-axis

0.0043×10-8 Ohm m

polycrystalline

0.0332×10-8 Ohm m

7 K

perpendicular to c-axis

0.0072×10-8 Ohm m

parallel to c-axis

0.0043×10-8 Ohm m

polycrystalline

0.0332×10-8 Ohm m

4 K

perpendicular to c-axis

0.0072×10-8 Ohm m

parallel to c-axis

0.0043×10-8 Ohm m

polycrystalline

0.0332×10-8 Ohm m

1 K

perpendicular to c-axis

0.0072×10-8 Ohm m

parallel to c-axis

0.0043×10-8 Ohm m

polycrystalline

0.0332×10-8 Ohm m

Bismuth

solid, 295 K

116×10-8 Ohm m

Cadmium

solid, 295 K

7.27×10-8 Ohm m

Calcium

liquid

1150 K

33.0×10-8 Ohm m

1113 K

33.0×10-8 Ohm m

solid

1113 K

14.5×10-8 Ohm m

1100 K

14.3×10-8 Ohm m

1000 K

12.8×10-8 Ohm m

950 K

12.1×10-8 Ohm m

900 K

11.4×10-8 Ohm m

850 K

10.7×10-8 Ohm m

800 K

10.0×10-8 Ohm m

750 K

9.38×10-8 Ohm m

700 K

8.70×10-8 Ohm m

650 K

8.02×10-8 Ohm m

600 K

7.35×10-8 Ohm m

550 K

6.68×10-8 Ohm m

500 K

6.02×10-8 Ohm m

450 K

5.37×10-8 Ohm m

400 K

4.73×10-8 Ohm m

350 K

4.09×10-8 Ohm m

300 K

3.45×10-8 Ohm m

293 K

3.36×10-8 Ohm m

273.15 K

3.11×10-8 Ohm m

250 K

2.82×10-8 Ohm m

225 K

2.51×10-8 Ohm m

200 K

2.19×10-8 Ohm m

175 K

1.88×10-8 Ohm m

150 K

1.56×10-8 Ohm m

140 K

1.43×10-8 Ohm m

130 K

1.30×10-8 Ohm m

120 K

1.17×10-8 Ohm m

110 K

1.04×10-8 Ohm m

100 K

0.913×10-8 Ohm m

90 K

0.782×10-8 Ohm m

80 K

0.652×10-8 Ohm m

70 K

0.522×10-8 Ohm m

60 K

0.396×10-8 Ohm m

50 K

0.277×10-8 Ohm m

45 K

0.224×10-8 Ohm m

40 K

0.175×10-8 Ohm m

35 K

0.133×10-8 Ohm m

30 K

0.100×10-8 Ohm m

25 K

0.075×10-8 Ohm m

20 K

0.060×10-8 Ohm m

15 K

0.051×10-8 Ohm m

10 K

0.047×10-8 Ohm m

7 K

0.046×10-8 Ohm m

4 K

0.045×10-8 Ohm m

1 K

0.045×10-8 Ohm m

Carbon

diamond, solid

Type I and most Type IIa

1×1018 Ohm m

Type IIb

1×103 Ohm m to 1×105 Ohm m

graphite, solid, 298.15 K

Electrographite (from petroleum coke)

7.6×10-6 Ohm m

Electrographite (from lampblack)

30.5×10-6 Ohm m

Pyrolytic graphite (ab direction - parallel to the basal planes)

2.5×10-6 Ohm m to 5.0×10-6 Ohm m

References (Click the next to a value above to see complete citation information for that entry)

Chi, T. C. "Electrical Resistivity of Alkaline Earth Elements." Journal of Physical and Chemical Reference Data, volume 8, number 2, 1979, pp. 439–498.

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.

Pierson, Hugh O. Handbook of Carbon, Graphite, Diamond and Fullerenes. Park Ridge, NJ: Noyes Publications, 1993.
