Element

Click button to see citations

Lutetium

solid, 295 K

53×10-8 Ohm m

Magnesium

liquid

1200 K, polycrystalline

25.6×10-8 Ohm m

1150 K, polycrystalline

25.7×10-8 Ohm m

1100 K, polycrystalline

25.8×10-8 Ohm m

1050 K, polycrystalline

25.9×10-8 Ohm m

1000 K, polycrystalline

26.0×10-8 Ohm m

950 K, polycrystalline

26.1×10-8 Ohm m

922 K, polycrystalline

26.1×10-8 Ohm m

solid

922 K, polycrystalline

14.7×10-8 Ohm m

900 K, polycrystalline

14.4×10-8 Ohm m

850 K, polycrystalline

13.6×10-8 Ohm m

800 K, polycrystalline

12.8×10-8 Ohm m

750 K, polycrystalline

12.0×10-8 Ohm m

700 K

perpendicular to c-axis

11.4×10-8 Ohm m

parallel to c-axis

9.78×10-8 Ohm m

polycrystalline

11.2×10-8 Ohm m

650 K

perpendicular to c-axis

10.6×10-8 Ohm m

parallel to c-axis

9.07×10-8 Ohm m

polycrystalline

10.4×10-8 Ohm m

600 K

perpendicular to c-axis

9.76×10-8 Ohm m

parallel to c-axis

8.35×10-8 Ohm m

polycrystalline

9.52×10-8 Ohm m

550 K

perpendicular to c-axis

8.93×10-8 Ohm m

parallel to c-axis

7.53×10-8 Ohm m

polycrystalline

8.69×10-8 Ohm m

500 K

perpendicular to c-axis

8.09×10-8 Ohm m

parallel to c-axis

6.90×10-8 Ohm m

polycrystalline

7.86×10-8 Ohm m

450 K

perpendicular to c-axis

7.25×10-8 Ohm m

parallel to c-axis

6.16×10-8 Ohm m

polycrystalline

7.03×10-8 Ohm m

400 K

perpendicular to c-axis

6.39×10-8 Ohm m

parallel to c-axis

5.42×10-8 Ohm m

polycrystalline

6.19×10-8 Ohm m

350 K

perpendicular to c-axis

5.52×10-8 Ohm m

parallel to c-axis

4.68×10-8 Ohm m

polycrystalline

5.36×10-8 Ohm m

300 K

perpendicular to c-axis

4.67×10-8 Ohm m

parallel to c-axis

3.94×10-8 Ohm m

polycrystalline

4.51×10-8 Ohm m

293 K

perpendicular to c-axis

4.55×10-8 Ohm m

parallel to c-axis

3.84×10-8 Ohm m

polycrystalline

4.39×10-8 Ohm m

273.15 K

perpendicular to c-axis

4.20×10-8 Ohm m

parallel to c-axis

3.54×10-8 Ohm m

polycrystalline

4.05×10-8 Ohm m

250 K

perpendicular to c-axis

3.80×10-8 Ohm m

parallel to c-axis

3.19×10-8 Ohm m

polycrystalline

3.61×10-8 Ohm m

225 K

perpendicular to c-axis

3.35×10-8 Ohm m

parallel to c-axis

2.81×10-8 Ohm m

polycrystalline

3.19×10-8 Ohm m

200 K

perpendicular to c-axis

2.90×10-8 Ohm m

parallel to c-axis

2.42×10-8 Ohm m

polycrystalline

2.75×10-8 Ohm m

175 K

perpendicular to c-axis

2.44×10-8 Ohm m

parallel to c-axis

2.02×10-8 Ohm m

polycrystalline

2.30×10-8 Ohm m

150 K

perpendicular to c-axis

1.96×10-8 Ohm m

parallel to c-axis

1.63×10-8 Ohm m

polycrystalline

1.84×10-8 Ohm m

140 K

perpendicular to c-axis

1.77×10-8 Ohm m

parallel to c-axis

1.47×10-8 Ohm m

polycrystalline

1.66×10-8 Ohm m

130 K

perpendicular to c-axis

1.58×10-8 Ohm m

parallel to c-axis

1.31×10-8 Ohm m

polycrystalline

1.47×10-8 Ohm m

120 K

perpendicular to c-axis

1.38×10-8 Ohm m

parallel to c-axis

1.15×10-8 Ohm m

polycrystalline

1.28×10-8 Ohm m

110 K

perpendicular to c-axis

1.18×10-8 Ohm m

parallel to c-axis

0.986×10-8 Ohm m

polycrystalline

1.10×10-8 Ohm m

100 K

perpendicular to c-axis

0.983×10-8 Ohm m

parallel to c-axis

0.827×10-8 Ohm m

polycrystalline

0.908×10-8 Ohm m

90 K

perpendicular to c-axis

0.789×10-8 Ohm m

parallel to c-axis

0.671×10-8 Ohm m

polycrystalline

0.728×10-8 Ohm m

80 K

perpendicular to c-axis

0.603×10-8 Ohm m

parallel to c-axis

0.520×10-8 Ohm m

polycrystalline

0.557×10-8 Ohm m

70 K

perpendicular to c-axis

0.430×10-8 Ohm m

parallel to c-axis

0.381×10-8 Ohm m

polycrystalline

0.398×10-8 Ohm m

60 K

perpendicular to c-axis

0.282×10-8 Ohm m

parallel to c-axis

0.255×10-8 Ohm m

polycrystalline

0.261×10-8 Ohm m

50 K

perpendicular to c-axis

0.164×10-8 Ohm m

parallel to c-axis

0.151×10-8 Ohm m

polycrystalline

0.151×10-8 Ohm m

45 K

perpendicular to c-axis

0.119×10-8 Ohm m

parallel to c-axis

0.110×10-8 Ohm m

polycrystalline

0.109×10-8 Ohm m

40 K

perpendicular to c-axis

0.0837×10-8 Ohm m

parallel to c-axis

0.0760×10-8 Ohm m

polycrystalline

0.0744×10-8 Ohm m

35 K

perpendicular to c-axis

0.0572×10-8 Ohm m

parallel to c-axis

0.0502×10-8 Ohm m

polycrystalline

0.0488×10-8 Ohm m

30 K

perpendicular to c-axis

0.0383×10-8 Ohm m

parallel to c-axis

0.0320×10-8 Ohm m

polycrystalline

0.0309×10-8 Ohm m

25 K

perpendicular to c-axis

0.0255×10-8 Ohm m

parallel to c-axis

0.0204×10-8 Ohm m

polycrystalline

0.0193×10-8 Ohm m

20 K

perpendicular to c-axis

0.0175×10-8 Ohm m

parallel to c-axis

0.0136×10-8 Ohm m

polycrystalline

0.0123×10-8 Ohm m

15 K

perpendicular to c-axis

0.0130×10-8 Ohm m

parallel to c-axis

0.0101×10-8 Ohm m

polycrystalline

0.0086×10-8 Ohm m

10 K

perpendicular to c-axis

0.0108×10-8 Ohm m

parallel to c-axis

0.0086×10-8 Ohm m

polycrystalline

0.0069×10-8 Ohm m

7 K

perpendicular to c-axis

0.0100×10-8 Ohm m

parallel to c-axis

0.0082×10-8 Ohm m

polycrystalline

0.0064×10-8 Ohm m

4 K

perpendicular to c-axis

0.0100×10-8 Ohm m

parallel to c-axis

0.0080×10-8 Ohm m

polycrystalline

0.0062×10-8 Ohm m

1 K

perpendicular to c-axis

0.0100×10-8 Ohm m

parallel to c-axis

0.0080×10-8 Ohm m

polycrystalline

0.0062×10-8 Ohm m

Manganese

solid

700 K

153.6×10-8 Ohm m

600 K

152.1×10-8 Ohm m

500 K

150.1×10-8 Ohm m

400 K

147.7×10-8 Ohm m

350 K

146.1×10-8 Ohm m

300 K

144.2×10-8 Ohm m

293 K

144.0×10-8 Ohm m

273 K

143.0×10-8 Ohm m

250 K

141.9×10-8 Ohm m

200 K

139.1×10-8 Ohm m

150 K

135.9×10-8 Ohm m

100 K

132.1×10-8 Ohm m

94 K

131.4×10-8 Ohm m

90 K

131.5×10-8 Ohm m

80 K

132.0×10-8 Ohm m

70 K

132.5×10-8 Ohm m

60 K

130.7×10-8 Ohm m

50 K

126.1×10-8 Ohm m

40 K

115.6×10-8 Ohm m

30 K

93.4×10-8 Ohm m

25 K

75.6×10-8 Ohm m

20 K

53.6×10-8 Ohm m

15 K

33.8×10-8 Ohm m

10 K

18.84×10-8 Ohm m

7 K

12.74×10-8 Ohm m

4 K

8.79×10-8 Ohm m

1 K

7.00×10-8 Ohm m

0 K

6.88×10-8 Ohm m

References (Click the next to a value above to see complete citation information for that entry)

Chi, T. C. "Electrical Resistivity of Alkaline Earth Elements." Journal of Physical and Chemical Reference Data, volume 8, number 2, 1979, pp. 439–498.

Desai, P. D., H. M. James, and C. Y. Ho. "Electrical Resistivity of Aluminum and Manganese." Journal of Physical and Chemical Reference Data, volume 13, number 4, 1984, pp. 1131–1172.

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.
