Thermal Conductivity

Thermal Conductivity Navigation

By Name

By Symbol

By Number

Nitrogen to Phosphorus

Element

Click button to see citations

Notes

Nitrogen

gas

2500 K, 1 atm

0.1406 W/(m K)

extrapolated or estimated

2300 K, 1 atm

0.1314 W/(m K)

extrapolated or estimated

2100 K, 1 atm

0.1207 W/(m K)

extrapolated or estimated

1900 K, 1 atm

0.1080 W/(m K)

extrapolated or estimated

1700 K, 1 atm

0.0950 W/(m K)

extrapolated or estimated

1500 K, 1 atm

0.0842 W/(m K)

1300 K, 1 atm

0.0754 W/(m K)

1100 K, 1 atm

0.0672 W/(m K)

900 K, 1 atm

0.0587 W/(m K)

700 K, 1 atm

0.0493 W/(m K)

500 K, 1 atm

0.03864 W/(m K)

400 K, 1 atm

0.03252 W/(m K)

300 K, 1 atm

0.02598 W/(m K)

290 K, 1 atm

0.02524 W/(m K)

280 K, 1 atm

0.02449 W/(m K)

270 K, 1 atm

0.02374 W/(m K)

200 K, 1 atm

0.01826 W/(m K)

100 K, 1 atm

0.00941 W/(m K)

78 K, 1 atm

0.00745 W/(m K)

saturated vapor

126 K

0.037 W/(m K)

extrapolated or estimated, pseudo-critical value

125 K

0.0265 W/(m K)

extrapolated or estimated

120 K

0.0195 W/(m K)

extrapolated or estimated

110 K

0.0138 W/(m K)

extrapolated or estimated

100 K

0.0111 W/(m K)

extrapolated or estimated

90 K

0.0091 W/(m K)

extrapolated or estimated

80 K

0.0077 W/(m K)

extrapolated or estimated

70 K

0.0066 W/(m K)

extrapolated or estimated

60 K

0.0056 W/(m K)

extrapolated or estimated

saturated liquid

126 K

0.037 W/(m K)

extrapolated or estimated, pseudo-critical value

125 K

0.0520 W/(m K)

extrapolated or estimated

120 K

0.0628 W/(m K)

110 K

0.0795 W/(m K)

100 K

0.0966 W/(m K)

90 K

0.1142 W/(m K)

80 K

0.1322 W/(m K)

70 K

0.151 W/(m K)

solid

25 K

0.32 W/(m K)

23 K

0.35 W/(m K)

21 K

0.38 W/(m K)

19 K

0.45 W/(m K)

17 K

0.56 W/(m K)

15 K

0.76 W/(m K)

13 K

1.0 W/(m K)

11 K

1.4 W/(m K)

10 K

1.7 W/(m K)

9 K

2.0 W/(m K)

8 K

2.5 W/(m K)

7 K

3.0 W/(m K)

6 K

3.7 W/(m K)

5 K

4.5 W/(m K)

4 K

5.6 W/(m K)

Osmium

solid

500 K, polycrystalline

86.9 W/(m K)

400 K, polycrystalline

86.9 W/(m K)

350 K, polycrystalline

87.0 W/(m K)

300 K, polycrystalline

87.6 W/(m K)

extrapolated or interpolated

298.2 K, polycrystalline

87.6 W/(m K)

extrapolated or interpolated

273.2 K, polycrystalline

88.0 W/(m K)

extrapolated or interpolated

250 K, polycrystalline

88.6 W/(m K)

extrapolated or interpolated

200 K, polycrystalline

90.8 W/(m K)

extrapolated or interpolated

150 K, polycrystalline

96.2 W/(m K)

extrapolated or interpolated

100 K, polycrystalline

114 W/(m K)

80 K, polycrystalline

139 W/(m K)

60 K, polycrystalline

218 W/(m K)

40 K, polycrystalline

638 W/(m K)

20 K

polycrystalline

16.0×102 W/(m K)

parallel to c-axis

21.5×102 W/(m K)

perpendicular to c-axis

13.8×102 W/(m K)

18 K

polycrystalline

15.7×102 W/(m K)

parallel to c-axis

21.3×102 W/(m K)

perpendicular to c-axis

13.4×102 W/(m K)

16 K

polycrystalline

14.9×102 W/(m K)

parallel to c-axis

20.4×102 W/(m K)

perpendicular to c-axis

12.7×102 W/(m K)

14 K

polycrystalline

13.7×102 W/(m K)

parallel to c-axis

18.9×102 W/(m K)

perpendicular to c-axis

11.6×102 W/(m K)

12 K

polycrystalline

12.1×102 W/(m K)

parallel to c-axis

16.8×102 W/(m K)

perpendicular to c-axis

10.2×102 W/(m K)

10 K

polycrystalline

10.2×102 W/(m K)

parallel to c-axis

14.3×102 W/(m K)

perpendicular to c-axis

865 W/(m K)

8 K

polycrystalline

829 W/(m K)

parallel to c-axis

11.6×102 W/(m K)

perpendicular to c-axis

699 W/(m K)

6 K

polycrystalline

626 W/(m K)

parallel to c-axis

877 W/(m K)

perpendicular to c-axis

527 W/(m K)

4 K

polycrystalline

418 W/(m K)

parallel to c-axis

586 W/(m K)

perpendicular to c-axis

352 W/(m K)

2 K

polycrystalline

209 W/(m K)

parallel to c-axis

293 W/(m K)

perpendicular to c-axis

176 W/(m K)

Oxygen

gas

1500 K, 1 atm

0.0970 W/(m K)

1300 K, 1 atm

0.0871 W/(m K)

1100 K, 1 atm

0.0771 W/(m K)

900 K, 1 atm

0.0661 W/(m K)

700 K, 1 atm

0.0544 W/(m K)

500 K, 1 atm

0.0412 W/(m K)

400 K, 1 atm

0.0342 W/(m K)

300 K, 1 atm

0.02674 W/(m K)

290 K, 1 atm

0.02592 W/(m K)

280 K, 1 atm

0.02509 W/(m K)

270 K, 1 atm

0.02424 W/(m K)

200 K, 1 atm

0.01824 W/(m K)

100 K, 1 atm

0.00905 W/(m K)

saturated vapor

155 K

0.041 W/(m K)

extrapolated or estimated, pseudo-critical value

150 K

0.025 W/(m K)

extrapolated or estimated

145 K

0.021 W/(m K)

extrapolated or estimated

140 K

0.018 W/(m K)

extrapolated or estimated

135 K

0.016 W/(m K)

extrapolated or estimated

130 K

0.015 W/(m K)

extrapolated or estimated

125 K

0.0135 W/(m K)

extrapolated or estimated

120 K

0.0124 W/(m K)

extrapolated or estimated

115 K

0.0116 W/(m K)

extrapolated or estimated

110 K

0.0108 W/(m K)

extrapolated or estimated

105 K

0.0100 W/(m K)

extrapolated or estimated

100 K

0.0093 W/(m K)

extrapolated or estimated

95 K

0.0087 W/(m K)

extrapolated or estimated

90 K

0.0081 W/(m K)

extrapolated or estimated

saturated liquid

155 K

0.041 W/(m K)

extrapolated or estimated, pseudo-critical value

150 K

0.0610 W/(m K)

145 K

0.0712 W/(m K)

140 K

0.0796 W/(m K)

135 K

0.0873 W/(m K)

130 K

0.0949 W/(m K)

125 K

0.1023 W/(m K)

120 K

0.1096 W/(m K)

115 K

0.1168 W/(m K)

110 K

0.1237 W/(m K)

105 K

0.1306 W/(m K)

100 K

0.1372 W/(m K)

95 K

0.1437 W/(m K)

90 K

0.1501 W/(m K)

85 K

0.1563 W/(m K)

80 K

0.1623 W/(m K)

75 K

0.1682 W/(m K)

70 K

0.174 W/(m K)

65 K

0.180 W/(m K)

60 K

0.185 W/(m K)

55 K

0.190 W/(m K)

Palladium

solid

1800 K

115 W/(m K)

extrapolated or interpolated

1700 K

114 W/(m K)

1600 K

112 W/(m K)

1500 K

110 W/(m K)

1400 K

107 W/(m K)

1300 K

105 W/(m K)

1200 K

102 W/(m K)

1100 K

98.1 W/(m K)

1000 K

94.2 W/(m K)

900 K

90.6 W/(m K)

800 K

86.9 W/(m K)

700 K

83.3 W/(m K)

600 K

79.7 W/(m K)

500 K

76.3 W/(m K)

400 K

73.6 W/(m K)

350 K

72.6 W/(m K)

300 K

71.8 W/(m K)

298.2 K

71.8 W/(m K)

273.2 K

71.6 W/(m K)

extrapolated or interpolated

250 K

71.5 W/(m K)

extrapolated or interpolated

200 K

71.6 W/(m K)

extrapolated or interpolated

150 K

72.7 W/(m K)

100 K

76.5 W/(m K)

90 K

78.3 W/(m K)

80 K

81.1 W/(m K)

70 K

86.8 W/(m K)

60 K

98.3 W/(m K)

50 K

124 W/(m K)

40 K

173 W/(m K)

20 K

598 W/(m K)

18 K

708 W/(m K)

16 K

828 W/(m K)

14 K

949 W/(m K)

12 K

10.7×102 W/(m K)

10 K

11.5×102 W/(m K)

9 K

11.7×102 W/(m K)

8 K

11.6×102 W/(m K)

7 K

11.1×102 W/(m K)

6 K

10.3×102 W/(m K)

5 K

913 W/(m K)

4 K

761 W/(m K)

3 K

586 W/(m K)

2 K

396 W/(m K)

extrapolated or interpolated

1 K

199 W/(m K)

extrapolated or interpolated

Phosphorus

black phosphorus, solid

300 K, polycrystalline

12.1 W/(m K)

298.2 K, polycrystalline

12.1 W/(m K)

273.2 K, polycrystalline

13.2 W/(m K)

250 K, polycrystalline

14.4 W/(m K)

200 K, polycrystalline

17.7 W/(m K)

150 K, polycrystalline

22.7 W/(m K)

100 K, polycrystalline

30.7 W/(m K)

90 K, polycrystalline

32.8 W/(m K)

80 K, polycrystalline

35.2 W/(m K)

70 K, polycrystalline

37.7 W/(m K)

60 K, polycrystalline

40.2 W/(m K)

50 K, polycrystalline

42.7 W/(m K)

40 K, polycrystalline

43.5 W/(m K)

30 K, polycrystalline

40.1 W/(m K)

20 K, polycrystalline

27.2 W/(m K)

18 K, polycrystalline

23.0 W/(m K)

16 K, polycrystalline

18.7 W/(m K)

15 K, polycrystalline

16.5 W/(m K)

14 K, polycrystalline

14.4 W/(m K)

13 K, polycrystalline

12.2 W/(m K)

12 K, polycrystalline

10.1 W/(m K)

11 K, polycrystalline

8.22 W/(m K)

10 K, polycrystalline

6.53 W/(m K)

9 K, polycrystalline

4.97 W/(m K)

8 K, polycrystalline

3.67 W/(m K)

7 K, polycrystalline

2.55 W/(m K)

6 K, polycrystalline

1.67 W/(m K)

5 K, polycrystalline

0.998 W/(m K)

4 K, polycrystalline

0.511 W/(m K)

3 K, polycrystalline

0.220 W/(m K)

2 K, polycrystalline

0.0645 W/(m K)

extrapolated

1 K, polycrystalline

0.00796 W/(m K)

extrapolated

white phosphorus

liquid

500 K

0.167 W/(m K)

extrapolated

473.2 K

0.170 W/(m K)

extrapolated

400 K

0.178 W/(m K)

extrapolated

373.2 K

0.181 W/(m K)

extrapolated

350 K

0.183 W/(m K)

extrapolated

323.2 K

0.187 W/(m K)

317.3 K

0.187 W/(m K)

solid

317.3 K

0.226 W/(m K)

extrapolated

300 K

0.235 W/(m K)

298.2 K

0.236 W/(m K)

extrapolated

273.2 K

0.250 W/(m K)

extrapolated

250 K

0.265 W/(m K)

extrapolated

223.2 K

0.287 W/(m K)

extrapolated

200 K

0.308 W/(m K)

extrapolated

Reference (Click the next to a value above to see complete citation information for that entry)

Ho, C. Y., R. W. Powell, and P. E. Liley. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 3, supplement 1, 1974, pp. I–1 to I–796.
