Neon

Neon Navigation

Other Elements

By Name

By Symbol

By Number

Quantity

Neon Quick Reference

Click button to see citations

Notes

Symbol

Ne

Atomic Number

10

Atomic Weight

Rounded

20.180

for regular calculations

Standard

20.1797 ± 0.0006

for precise calculations

Oxidation States

0

Electron Configuration

Orbital Occupancy

[He] 2s2 2p6

[He] represents the closed-shell electron configuration of helium

Orbital Filling Order

[He] 2s2 2p6

[He] represents the closed-shell electron configuration of helium

Term Symbol

1S0

see expanded configuration ...

Ionization Energies

I   (1)

21.56454 eV

II  (2)

40.96296 eV

III (3)

63.45 eV

IV  (4)

97.12 eV

see all 10 energies ...

Electron Affinity

<0 eV

<0 cm-1

Density

gas

25 °C, 1 atm

0.825 g/L

273.15 K, 1 atm

0.9003 g/L

liquid, 24.56 K

1.247 g/ml

solid, 4 K

1.51 g/cm3

Molar Volume

gas, 273.15 K, 1 atm

22.4139 L/mol

liquid, 24.5561 K, 43 kPa

16.18 ml/mol

solid

24.5561 K, 43 kPa

14.17 cm3/mol

0 K, 0 atm

13.39 cm3/mol

Melting Point

54.5 kbar

327.9 K

46.6 kbar

294.2 K

45.4 kbar

288.4 K

41.3 kbar

270.6 K

21.8 kbar

177.4 K

1 bar

 25.24 K

see all 11 melting points ...

Boiling Point

1 atm

27.097 K

ITS-90 first-quality, secondary reference point

Thermal Conductivity

gas

400 K, 1 atm

0.0590 W/(m K)

300 K, 1 atm

0.0493 W/(m K)

290 K, 1 atm

0.0483 W/(m K)

280 K, 1 atm

0.0472 W/(m K)

270 K, 1 atm

0.0461 W/(m K)

200 K, 1 atm

0.0375 W/(m K)

see all 52 conductivities ...

Pyykkö Covalent Radius

single bond

67 pm

double bond

96 pm

Enthalpy of Fusion

1 atm

0.324 kJ/mol

Enthalpy of Vaporization

1 atm

1.1736 kJ/mol

Quantity

Neon Atomic Structure

Notes

Ionization Energies

I   (1)

21.56454 eV

II  (2)

40.96296 eV

III (3)

63.45 eV

IV  (4)

97.12 eV

see all 10 energies ...

Electron Affinity

<0 eV

<0 cm-1

Electron Binding Energies

K    (1s)

870.2 eV

LI   (2s)

 48.5 eV

LII  (2p1/2)

 21.7 eV

LIII (2p3/2)

 21.6 eV

Electron Configuration

Orbital Occupancy

[He] 2s2 2p6

[He] represents the closed-shell electron configuration of helium

Orbital Filling Order

[He] 2s2 2p6

[He] represents the closed-shell electron configuration of helium

Term Symbol

1S0

see expanded configuration ...

Clementi-Raimondi Effective Nuclear Charge

1s

Orbital Exponent

9.6421

ζ

Principle Quantum Number

1

n

Effective Nuclear Charge

9.6421

Zeff = ζ × n

2s

Orbital Exponent

2.8792

ζ

Principle Quantum Number

2

n

Effective Nuclear Charge

5.7584

Zeff = ζ × n

2p

Orbital Exponent

2.8792

ζ

Principle Quantum Number

2

n

Effective Nuclear Charge

5.7584

Zeff = ζ × n

Screening Percentage

41.5%

Fluorescence Yields

ωK

0.015

Quantity

Neon Physical Properties

Notes

Density

gas

25 °C, 1 atm

0.825 g/L

273.15 K, 1 atm

0.9003 g/L

liquid, 24.56 K

1.247 g/ml

solid, 4 K

1.51 g/cm3

Molar Mass

Rounded

20.180 g/mol

for regular calculations

Standard

20.1797 ± 0.0006 g/mol

for precise calculations

Molar Volume

gas, 273.15 K, 1 atm

22.4139 L/mol

liquid, 24.5561 K, 43 kPa

16.18 ml/mol

solid

24.5561 K, 43 kPa

14.17 cm3/mol

0 K, 0 atm

13.39 cm3/mol

Physical Form

colorless gas

Speed of Sound

gas, 0 °C, 1 atm

435 m/s

liquid

936 m/s

calculated value

Dielectric Constant

20 °C, 1 atm

1.00013

26.11 K

1.19

Isothermal Bulk Modulus

4 K

1.0 GPa

Isothermal Compressibility

4 K

1.00 GPa-1

Gram Atomic Volume

17 cm3

Quantity

Neon Atomic Interaction

Notes

Oxidation States

0

Mulliken-Jaffe Electronegativity

hybridsp3

4.49

hybrid12.5% s

3.98

orbitalp

3.41

Sanderson Electronegativity

4.50

Allred-Rochow Electronegativity

4.84

Configuration Energy

electron volt units

28.31 eV

Pauling units

 4.787

Allen Electronegativity

4.787

Ghosh-Gupta Electronegativity

11.3003 eV

Nagle Electronegativity

4.89

Cohesive Energy

per mole

1.92 kJ/mol

per atom

0.020 eV/atom

Quantity

Neon Thermodynamics

Notes

Melting Point

54.5 kbar

327.9 K

46.6 kbar

294.2 K

45.4 kbar

288.4 K

41.3 kbar

270.6 K

21.8 kbar

177.4 K

1 bar

 25.24 K

see all 11 melting points ...

Boiling Point

1 atm

27.097 K

ITS-90 first-quality, secondary reference point

Thermal Conductivity

gas

400 K, 1 atm

0.0590 W/(m K)

300 K, 1 atm

0.0493 W/(m K)

290 K, 1 atm

0.0483 W/(m K)

280 K, 1 atm

0.0472 W/(m K)

270 K, 1 atm

0.0461 W/(m K)

200 K, 1 atm

0.0375 W/(m K)

see all 52 conductivities ...

Triple Point

temperature

24.5561 K

ITS-90 fixed point

pressure

43 kPa

neon-20

24.541 K

ITS-90 first-quality, secondary reference point

Critical Point

44.4 K

Vapor Pressure

-246.1 °C

100 kPa

-252 °C

10 kPa

-255 °C

1 kPa

see all 26 pressures ...

Enthalpy of Fusion

1 atm

0.324 kJ/mol

Enthalpy of Vaporization

1 atm

1.1736 kJ/mol

Isobaric Molar Heat Capacity

298.15 K, 1 bar

20.786 J/(mol K)

Isobaric Specific Heat Capacity

298.15 K, 1 bar

1.030 J/(g K)

Debye Temperature

Low Temperature Limit ( 0 K )

74.6 K

Quantity

Neon Identification

Notes

CAS Number

7440-01-9

DOT Number

1065

compressed

1065

refrigerated liquid (cryogenic liquid)

1913

ICSC Number

0627

RTECS Number

QP4450000

UN Number

1065

Quantity

Neon Atomic Size

Notes

Orbital Radius

35.4 pm

Pyykkö Covalent Radius

single bond

67 pm

double bond

96 pm

Cordero Covalent Radius

58 pm

Pauling Univalent Radius

ion charge: 0

112 pm

Bondi Van Der Waals Radius

154 pm

Quantity

Neon Crystal Structure

Notes

Nearest Neighbor Distance

4 K, 1 atm

316 pm

Atomic Concentration

4 K, 1 atm

4.36×1022 cm-3

Quantity

Neon History

Notes

Discovery

date of discovery

1898

discoverer

William Ramsay

birth

October 2, 1852

death

July 23, 1916

discoverer

Morris William Travers

birth

January 24, 1872

death

1961

location of discovery

London, England

Origin of Element Name

origin

neos

origin description

word—Greek for new

Origin of Element Symbol

symbol: Ne

origin

neon

origin description

element name

U.S. Towns Named After Elements

Neon, Kentucky

Quantity

Neon Abundances

Notes

Earth's Crust

5×10-3 ppm

Earth's Atmosphere

18.18 ppm

Ocean Water

0.00012 ppm

Universe

0.00012

relative to hydrogen = 1.00000

Solar System

3.44×106

number of atoms for every 106 atoms of silicon

Sun

8.06 ± 0.10

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Quantity

Neon Nomenclature

Notes

Element Names in Other Languages

French

néon

German

Neon

Italian

neo

Spanish

neón

Portuguese

neônio

Anions or Anionic Substituent Groups

neonide

Cations or Cationic Substituent Groups

neon (general)

Ne+, neon(1+)

Ligands

neonido

Heteroatomic Anion

neonate

'a' Term—Substitutive Nomenclature

neona

'y' Term—Chains and Rings Nomenclature

neony

References    (Click the button next to a value above to see complete citation information for that entry)

Albright, Thomas A., and Jeremy K. Burdett. Problems in Molecular Orbital Theory. New York: Oxford University Press, 1992.

Allen, Leland C. "Electronegativity Is the Average One-Electron Energy of the Valence-Shell Electrons in Ground-State Free Atoms." Journal of the American Chemical Society, volume 111, number 25, 1989, pp. 9003–9014. doi:10.1021/ja00207a003

Allen, Leland C., and James E. Huheey. "The Definition of Electronegativity and the Chemistry of the Noble Gases." Journal of Inorganic and Nuclear Chemistry, volume 42, number 10, 1980, pp. 1523–1524. doi:10.1016/0022-1902(80)80132-1

Anders, Edward, and Nicolas Grevesse. "Abundances of the Elements: Meteoritic and Solar." Geochimica et Cosmochimica Acta, volume 53, number 1, 1989, pp. 197–214. doi:10.1016/0016-7037(89)90286-X

Andersen, T., H. K. Haugen, and H. Hotop. "Binding Energies in Atomic Negative Ions: III." Journal of Physical and Chemical Reference Data, volume 28, number 6, 1999, pp. 1511–1533.

Bedford, R. E., G. Bonnier, H. Maas, and F. Pavese. "Recommended Values of Temperature on the International Temperature Scale of 1990 for a Selected Set of Secondary Reference Points." Metrologia, volume 33, number 2, 1996, pp. 133–154. doi:10.1088/0026-1394/33/2/3

Bondi, A. "Van der Waals Volumes and Radii." The Journal of Physical Chemistry, volume 68, number 3, 1964, pp. 441–451. doi:10.1021/j100785a001

Bratsch, Steven G. "Revised Mulliken Electronegativities: I. Calculation and Conversion to Pauling Units." Journal of Chemical Education, volume 65, number 1, 1988, pp. 34–41. doi:10.1021/ed065p34

Cardona, M., and L. Ley, editors. Photoemission in Solids I: General Principles. Berlin: Springer-Verlag, 1978.

Chauvin, Remi. "Explicit Periodic Trend of van der Waals Radii." The Journal of Physical Chemistry, volume 96, number 23, 1992, pp. 9194–9197. doi:10.1021/j100202a023

Clementi, E., and D. L. Raimondi. "Atomic Screening Constants from SCF Functions." Journal of Chemical Physics, volume 38, number 11, 1963, pp. 2686–2689. doi:10.1063/1.1733573

Cohen, E. Richard, David R. Lide, and George L. Trigg, editors. AlP Physics Desk Reference, 3rd edition. New York: Springer-Verlag New York, Inc., 2003.

Connelly, Neil G., Ture Damhus, Richard M. Hartshorn, and Alan T. Hutton. Nomenclature of Inorganic Chemistry: IUPAC Recommendations 2005. Cambridge: RSC Publishing, 2005.

Cordero, Beatriz, Verónica Gómez, Ana E. Platero-Prats, Marc Revés, Jorge Echeverría, Eduard Cremades, Flavia Barragán, and Santiago Alvarez. "Covalent Radii Revisited." Dalton Transactions, number 21, 2008, pp 2832–2838. doi:10.1039/b801115j

Cox, P. A. The Elements: Their Origin, Abundance and Distribution. Oxford: Oxford University Press, 1989.

Croswell, Ken. The Alchemy of the Heavens. New York: Anchor Books, 1995.

de Podesta, Michael. Understanding the Properties of Matter, 2nd edition. London: Taylor & Francis, 2002.

Emsley, John. Nature's Building Blocks: An A-Z Guide to the Elements. Oxford: Oxford University Press, 2003.

Emsley, John. The Elements, 3rd edition. Oxford: Oxford University Press, 1998.

Firestone, Richard B. Table of Isotopes, 8th edition, volume 2. Edited by Virginia S. Shirley, with assistant editors Coral M. Baglin, S. Y. Frank Chu, and Jean Zipkin. New York: John Wiley & Sons, Inc., 1996.

Ghosh, Dulal C., and Kartick Gupta. "A New Scale Of Electronegativity Of 54 Elements Of Periodic Table Based On Polarizability Of Atoms." Journal of Theoretical and Computational Chemistry, volume 5, number 4, 2006, pp. 895–911. doi:10.1142/S0219633606002726

Griffiths, David J. Introduction to Electrodynamics, 2nd edition. Upper Saddle River, NJ: Prentice-Hall Inc., 1989.

Gwyn Williams. Electron Binding Energies. http://www.jlab.org/~gwyn/ebindene.html. Accessed on April 30, 2010.

Halpern, Arthur M. "From Dimer to Crystal: Calculating the Cohesive Energy of Rare Gas Solids." Journal of Chemical Education, volume 89, number 5, 2012, pp. 592–597. doi:10.1021/ed200348j

Ho, C. Y., R. W. Powell, and P. E. Liley. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 3, supplement 1, 1974, pp. I–1 to I–796.

Horvath, A. L. "Critical Temperature of Elements and the Periodic System." Journal of Chemical Education, volume 50, number 5, 1973, pp. 335–336. doi:10.1021/ed050p335

Huheey, James E., Ellen A. Keiter, and Richard L Keiter. Inorganic Chemistry: Principles of Structure and Reactivity, 4th edition. New York: HarperCollins College Publishers, 1993.

Ihde, Aaron J. The Development of Modern Chemistry. New York: Dover Publications, Inc., 1984.

International Labour Organization (ILO). International Chemical Safety Card for Neon. http://www.ilo.org/legacy/english/protection/safework/cis/products/icsc/dtasht/_icsc06/icsc0627.htm. Accessed on May 5, 2010.

International Labour Organization (ILO). International Chemical Safety Card for Neon. http://www.ilo.org/legacy/english/protection/safework/cis/products/icsc/dtasht/_icsc06/icsc0627.htm. Accessed on May 4, 2010.

Jensen, William B. "Why Helium Ends in “-ium”." Journal of Chemical Education, volume 81, number 7, 2004, p. 944. doi:10.1021/ed081p944

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.

Liboff, Richard L. Introductory Quantum Mechanics, 3rd edition. Reading, MA: Addison Wesley Longman, Inc., 1998.

Lide, David R., editor. CRC Handbook of Chemistry and Physics, 88th edition. Boca Raton, Florida: Taylor & Francis Group, 2008.

Magomedov, M. N. "The Surface Energy of Cryocrystals." Technical Physics Letters, volume 31, number 12, 2005, pp. 1039–1042. doi:10.1134/1.2150892

Mann, Joseph B., Terry L. Meek, and Leland C. Allen. "Configuration Energies of the Main Group Elements." Journal of the American Chemical Society, volume 122, number 12, 2000, pp. 2780–2783. doi:10.1021/ja992866e

Manuel, O., editor. Origin of Elements in the Solar System: Implications of Post-1957 Observations. New York: Kluwer Academic Publishers, 2000.

Marshall, James L. Discovery of the Elements: A Search for the Fundamental Principles of the Universe, 2nd edition. Boston, MA: Pearson Custom Publishing, 2002.

Martin, W. C. "Electronic Structure of the Elements." The European Physical Journal C — Particles and Fields, volume 15, number 1–4, 2000, pp. 78–79. doi:10.1007/BF02683401

Mechtly, Eugene A. "Properties of Materials." pp. 4–1 to 4–33 in Reference Data For Engineers: Radio, Electronics, Computer, and Communications. By Mac E. Van Valkenburg, edited by Wendy M. Middleton. Woburn, MA: Butterworth-Heinemann, 2002. doi:10.1016/B978-075067291-7/50006-6

Miessler, Gary L., and Donald A. Tarr. Inorganic Chemistry, 3rd edition. Upper Saddle River, NJ: Pearson Prentice Hall, 2004.

Nagle, Jeffrey K. "Atomic Polarizability and Electronegativity." Journal of the American Chemical Society, volume 112, number 12, 1990, pp. 4741–4747. doi:10.1021/ja00168a019

National Aeronautics and Space Administration (NASA). Earth Fact Sheet. http://nssdc.gsfc.nasa.gov/planetary/factsheet/earthfact.html. Accessed on September 18, 2011.

National Institute for Occupational Safety and Health (NIOSH). International Chemical Safety Card for Neon. http://www.cdc.gov/niosh/ipcsneng/neng0627.html. Accessed on May 4, 2010.

National Institute for Occupational Safety and Health (NIOSH). International Chemical Safety Card for Neon. http://www.cdc.gov/niosh/ipcsneng/neng0627.html. Accessed on May 5, 2010.

National Institute for Occupational Safety and Health (NIOSH). The Registry of Toxic Effects of Chemical Substances for Neon. http://www.cdc.gov/niosh-rtecs/qp43e6d0.html. Accessed on May 5, 2010.

Nicholas, J. V., and D. R. White. "Temperature." pp. 8–41 in Measurement of the Thermodynamic Properties of Single Phases. Edited by A. R. H. Goodwin, W. A. Wakeham, and K. N. Marsh. Amsterdam: Elsevier Science, 2003.

Nobel Foundation. Sir William Ramsay: The Nobel Prize in Chemistry 1904. http://nobelprize.org/nobel_prizes/chemistry/laureates/1904/ramsay-bio.html. Accessed on July 16, 2009.

Oxtoby, David W., H. P. Gillis, and Alan Campion. Principles of Modern Chemistry, 6th edition. Belmont, CA: Thomson Brooks/Cole, 2008.

Pauling, Linus. The Nature of the Chemical Bond, 3rd edition. Ithaca, NY: Cornell University Press, 1960.

Pekka Pyykkö. Self-Consistent, Year-2009 Covalent Radii. http://www.chem.helsinki.fi/~pyykko/Radii09.pdf. Accessed on November 20, 2010.

Preston-Thomas, H. "The International Temperature Scale of 1990 (ITS-90)." Metrologia, volume 27, number 1, 1990, pp. 3–10. doi:10.1088/0026-1394/27/1/002

Prohaska, Thomas, Johanna Irrgeher, Jacqueline Benefield, John K. Böhlke, Lesley A. Chesson, Tyler B. Coplen, Tiping Ding, Philip J. H. Dunn, Manfred Gröning, Norman E. Holden, Harro A. J. Meijer, Heiko Moossen, Antonio Possolo, Yoshio Takahashi, Jochen Vogl, Thomas Walczyk, Jun Wang, Michael E. Wieser, Shigekazu Yoneda, Xiang-Kun Zhu, and Juris Meija. "Standard Atomic Weights of the Elements 2021 (IUPAC Technical Report)." Pure and Applied Chemistry, volume 94, number 5, 2022, pp. 573–600. doi:10.1515/pac-2019-0603

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Double-Bond Covalent Radii for Elements Li-E112." Chemistry - A European Journal, volume 15, number 46, 2009, pp. 12770–12779. doi:10.1002/chem.200901472

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Single-Bond Covalent Radii for Elements 1-118." Chemistry - A European Journal, volume 15, number 1, 2009, pp. 186–197. doi:10.1002/chem.200800987

Ringnes, Vivi. "Origin of the Names of Chemical Elements." Journal of Chemical Education, volume 66, number 9, 1989, pp. 731–738. doi:10.1021/ed066p731

Rohrer, Gregory S. Structure and Bonding in Crystalline Materials. Cambridge: Cambridge University Press, 2001.

Samsonov, G. V., editor. Handbook of the Physicochemical Properties of the Elements. New York: Plenum Publishing Corporation, 1968.

Sansonetti, J. E., and W. C. Martin. "Handbook of Basic Atomic Spectroscopic Data." Journal Of Physical And Chemical Reference Data, volume 34, number 4, 2005, pp. 1559–2259. doi:10.1063/1.1800011

Silbey, Robert J., Robert A. Alberty, and Moungi G. Bawendi. Physical Chemistry, 4th edition. Hoboken, NJ: John Wiley & Sons, Inc., 2005.

Stewart, G. R. "Measurement of Low-Temperature Specific Heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Tari, A. The Specific Heat of Matter at Low Temperatures. London: Imperial College Press, 2003.

Tonkov, E. Yu, and E. G. Ponyatovsky. Phase Transformations of Elements Under High Pressure. Advances in Metallic Alloys 4. Edited by J. N. Fridlyander and D. G. Eskin. Boca Raton, Florida: CRC Press LLC, 2005.

U. S. Department of Transportation (DOT), Transport Canada (TC), Secretariat of Transport and Communications of Mexico (SCT), and Centro de Información Química para Emergencias (CIQUIME). 2008 Emergency Response Guidebook.

Vos, W. L., J. A. Schouten, D. A. Young, and M. Ross. "The Melting Curve of Neon at High Pressure." Journal of Chemical Physics, volume 94, number 5, 1991, pp. 3835–3838. doi:10.1063/1.460683

Waber, J. T., and Don T. Cromer. "Orbital Radii of Atoms and Ions." Journal of Chemical Physics, volume 42, number 12, 1965, pp. 4116–4123. doi:10.1063/1.1695904

Wagman, Donald D., William H. Evans, Vivian B. Parker, Richard H. Schumm, Iva Halow, Sylvia M. Bailey, Kenneth L. Churney, and Ralph L. Nuttall. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 11, supplement 2, 1982, pp. 2–1 to 2–392.

Waldron, Kimberley A., Erin M. Fehringer, Amy E. Streeb, Jennifer E. Trosky, and Joshua J. Pearson. "Screening Percentages Based on Slater Effective Nuclear Charge as a Versatile Tool for Teaching Periodic Trends." Journal of Chemical Education, volume 78, number 5, 2001, pp. 635–639. doi:10.1021/ed078p635

Weeks, Mary Elvira, and Henry M. Leicester. Discovery of the Elements, 7th edition. Easton, PA: Journal of Chemical Education, 1968.

Yaws, Carl L. "Liquid Density of the Elements." Chemical Engineering, volume 114, number 12, 2007, pp. 44–46.

Yaws, Carl L. The Yaws Handbook of Physical Properties for Hydrocarbons and Chemicals. Houston, TX: Gulf Publishing Company, 2005.

Heaven's Boulevard astronomical sky image for any location, date, and time. Personalize with a picture and message. Great gift for birthdays, anniversaries, or any special event. Learn more (Link leaves KnowledgeDoor website)
