Ruthenium Quick Reference

Click button to see citations

Notes

Symbol

Ru

Atomic Number

44

Atomic Weight

Rounded

101.1

for regular calculations

Standard

101.07 ± 0.02

for precise calculations

Oxidation States

8

less common with disagreement

7

less common

6

less common with disagreement

5

less common

4

more common with disagreement

3

more common

2

less common with disagreement

1

less common

0

less common

2

less common

Pauling Electronegativity

2.2

Electron Configuration

Orbital Occupancy

[Kr] 4d7 5s1

[Kr] represents the closed-shell electron configuration of krypton

Orbital Filling Order

[Kr] 5s1 4d7

[Kr] represents the closed-shell electron configuration of krypton

Term Symbol

5F5

see expanded configuration ...

Ionization Energies

I   (1)

 7.36050 eV

II  (2)

16.76 eV

III (3)

28.47 eV

Electron Affinity

1.04638 ± 0.00025 eV

 8439.6 ± 2.0 cm-1

Density

liquid, 2607.15 K

10.900 g/ml

solid, 25 °C

12.100 g/cm3

Molar Volume

solid, 298 K, 1 atm

8.17 cm3/mol

Melting Point

1 atm

2606 K

ITS-90 second-quality, secondary reference point (melting point)

Boiling Point

1 atm

4592 ± 30 K

reference stated that the uncertainty may be larger than indicated

Thermal Conductivity

solid

400 K, polycrystalline

114 W/(m K)

273.2 K, polycrystalline

117 W/(m K)

200 K, polycrystalline

118 W/(m K)

see all 49 conductivities ...

Pyykkö Covalent Radius

single bond

125 pm

double bond

114 pm

triple bond

103 pm

Atomic Radius

134 pm

Enthalpy of Fusion

1 atm

23.7 kJ/mol

Enthalpy of Vaporization

1 atm

567.8 kJ/mol

Quantity

Ruthenium Atomic Structure

Notes

Ionization Energies

I   (1)

 7.36050 eV

II  (2)

16.76 eV

III (3)

28.47 eV

Electron Affinity

1.04638 ± 0.00025 eV

 8439.6 ± 2.0 cm-1

Electron Binding Energies

K    (1s)

22117 eV

LI   (2s)

 3224 eV

LII  (2p1/2)

 2967 eV

LIII (2p3/2)

 2838 eV

see all 12 energies ...

Electron Configuration

Orbital Occupancy

[Kr] 4d7 5s1

[Kr] represents the closed-shell electron configuration of krypton

Orbital Filling Order

[Kr] 5s1 4d7

[Kr] represents the closed-shell electron configuration of krypton

Term Symbol

5F5

see expanded configuration ...

Clementi-Raimondi Effective Nuclear Charge

1s

Orbital Exponent

43.0923

ζ

Principle Quantum Number

1

n

Effective Nuclear Charge

43.0923

Zeff = ζ × n

2s

Orbital Exponent

16.1899

ζ

Principle Quantum Number

2

n

Effective Nuclear Charge

32.3798

Zeff = ζ × n

see all 10 effective nuclear charges ...

Screening Percentage

87.0%

Fluorescence Yields

ωK

0.796

ωL1

0.012

ωL2

0.040

ωL3

0.043

Coster-Kronig Yields

F12

0.10

F13

0.57

F23

0.124

Quantity

Ruthenium Physical Properties

Notes

Density

liquid, 2607.15 K

10.900 g/ml

solid, 25 °C

12.100 g/cm3

Molar Mass

Rounded

101.1 g/mol

for regular calculations

Standard

101.07 ± 0.02 g/mol

for precise calculations

Molar Volume

solid, 298 K, 1 atm

8.17 cm3/mol

Physical Form

silvery-white metal

Linear Thermal Expansion Coefficient

25 °C

6.4×10-6 K-1

Speed of Sound

293 K

5970 m/s

calculated value

Young's Modulus

432 GPa

Poisson's Ratio

0.250

Electrical Resistivity

solid, 295 K

7.4×10-8 Ohm m

Contact Potential

4.52 eV

Superconducting Transition Temperature

ambient pressure

0.51 K

0 Pa

0.51 K

Superconducting Critical Magnetic Field at Absolute Zero

70×10-4 T

Mineralogical Hardness

6.5

Isothermal Bulk Modulus

300 K

320.8 GPa

Isothermal Compressibility

300 K

0.00311 GPa-1

Gram Atomic Volume

8 cm3

Quantity

Ruthenium Atomic Interaction

Notes

Oxidation States

8

less common with disagreement

7

less common

6

less common with disagreement

5

less common

4

more common with disagreement

3

more common

2

less common with disagreement

1

less common

0

less common

2

less common

Pauling Electronegativity

2.2

Allred-Rochow Electronegativity

1.42

Configuration Energy

electron volt units

9.100 eV

Pauling units

1.54

Ghosh-Gupta Electronegativity

3.3360 eV

Nagle Electronegativity

1.35

Pearson Absolute Electronegativity

4.5 eV

Chemical Hardness

3.0 eV

Cohesive Energy

per mole

650 kJ/mol

per atom

  6.74 eV/atom

Quantity

Ruthenium Thermodynamics

Notes

Melting Point

1 atm

2606 K

ITS-90 second-quality, secondary reference point (melting point)

Boiling Point

1 atm

4592 ± 30 K

reference stated that the uncertainty may be larger than indicated

Thermal Conductivity

solid

400 K, polycrystalline

114 W/(m K)

273.2 K, polycrystalline

117 W/(m K)

200 K, polycrystalline

118 W/(m K)

see all 49 conductivities ...

Critical Point

9600 K

Vapor Pressure

4592 K

1 atm

4588 K

1 bar

3965 K

1×10-1 bar

3498 K

1×10-2 bar

2606 K

1.045×10-5 bar

melting point

see all 19 pressures ...

Enthalpy of Fusion

1 atm

23.7 kJ/mol

Enthalpy of Vaporization

1 atm

567.8 kJ/mol

Isobaric Molar Heat Capacity

298.15 K, 1 bar

24.06 J/(mol K)

Isobaric Specific Heat Capacity

298.15 K, 1 bar

0.238 J/(g K)

Electronic Heat Capacity Coefficient

3.1 mJ/(mol K2)

Debye Temperature

Low Temperature Limit ( 0 K )

555 K

Room Temperature ( 298 K )

415 K

Quantity

Ruthenium Identification

Notes

CAS Number

7440-18-8

Quantity

Ruthenium Atomic Size

Notes

Atomic Radius

134 pm

Orbital Radius

141.0 pm

Pyykkö Covalent Radius

single bond

125 pm

double bond

114 pm

triple bond

103 pm

Cordero Covalent Radius

146 pm

Shannon-Prewitt Crystal Radius

ion charge: +3, coordination number: 6

82 pm

ion charge: +4, coordination number: 6

76.0 pm

ion charge: +5, coordination number: 6

70.5 pm

ion charge: +7, coordination number: 4

52 pm

ion charge: +8, coordination number: 4

50 pm

Shannon-Prewitt Effective Ionic Radius

ion charge: +3, coordination number: 6

68 pm

ion charge: +4, coordination number: 6

62.0 pm

ion charge: +5, coordination number: 6

56.5 pm

ion charge: +7, coordination number: 4

38 pm

ion charge: +8, coordination number: 4

36 pm

Batsanov Crystallographic Van Der Waals Radius

205 pm

Batsanov Equilibrium Van Der Waals Radius

237 pm

Slater Atomic-Ionic Radius

130 pm

Quantity

Ruthenium Crystal Structure

Notes

Nearest Neighbor Distance

300 K, 1 atm

265 pm

Atomic Concentration

300 K, 1 atm

7.36×1022 cm-3

Quantity

Ruthenium History

Notes

Discovery

date of discovery

1844

discoverer

Karl Karlovich Klaus

birth

January 23, 1796

death

March 24, 1864

location of discovery

Kazan, Russia

Origin of Element Name

origin

Ruthenia

origin description

place—Latin for Russia

Origin of Element Symbol

symbol: Ru

origin

ruthenium

origin description

element name

Formerly Used or Proposed Element Names and Symbols

name

vestium

no matching symbol specified

Quantity

Ruthenium Abundances

Notes

Earth's Crust

1×10-3 ppm

Earth's Mantle

4.55 ppb

primitive mantle

Earth's Core

4 ppm

Bulk Earth

1.3 ppm

Ocean Water

7×10-7 ppm

U.S. Coal

<0.001 ppm

estimated from USGS and literature data

Solar System

1.86

number of atoms for every 106 atoms of silicon

Sun

1.84 ± 0.07

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Meteorites

1.82 ± 0.04

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Quantity

Ruthenium Nomenclature

Notes

Element Names in Other Languages

French

ruthénium

German

Ruthenium

Italian

rutenio

Spanish

rutenio

Portuguese

ruténio

Anions or Anionic Substituent Groups

ruthenide

Cations or Cationic Substituent Groups

ruthenium

Ligands

ruthenido

Heteroatomic Anion

ruthenate

'a' Term—Substitutive Nomenclature

ruthena

'y' Term—Chains and Rings Nomenclature

rutheny

References    (Click the button next to a value above to see complete citation information for that entry)

Anders, Edward, and Nicolas Grevesse. "Abundances of the Elements: Meteoritic and Solar." Geochimica et Cosmochimica Acta, volume 53, number 1, 1989, pp. 197–214. doi:10.1016/0016-7037(89)90286-X

Andersen, T., H. K. Haugen, and H. Hotop. "Binding Energies in Atomic Negative Ions: III." Journal of Physical and Chemical Reference Data, volume 28, number 6, 1999, pp. 1511–1533.

Arblaster, J. W. "Vapour Pressure Equations for the Platinum Group Elements." Platinum Metals Review, volume 51, number 3, 2007, pp. 130–135. doi:10.1595/147106707X213830

Arblaster, J. W. "Thermodynamic Properties of the Platinum Metals on ITS-90." Platinum Metals Review, volume 40, number 2, 1996, pp. 62–63.

Batsanov, S. S. "Van der Waals Radii of Elements." Inorganic Materials, volume 37, number 9, 2001, pp. 871–885. See abstract

Bedford, R. E., G. Bonnier, H. Maas, and F. Pavese. "Recommended Values of Temperature on the International Temperature Scale of 1990 for a Selected Set of Secondary Reference Points." Metrologia, volume 33, number 2, 1996, pp. 133–154. doi:10.1088/0026-1394/33/2/3

Campbell, J. L. "Fluorescence Yields and Coster–Kronig Probabilities for the Atomic L Subshells." Atomic Data and Nuclear Data Tables, volume 85, number 2, 2003, pp. 291–315. doi:10.1016/S0092-640X(03)00059-7

Cardarelli, François. Materials Handbook: A Concise Desktop Reference, 2nd edition. London: Springer–Verlag, 2008.

Clementi, E., D. L. Raimondi, and W. P. Reinhardt. "Atomic Screening Constants from SCF Functions. II. Atoms with 37 to 86 Electrons." Journal of Chemical Physics, volume 47, number 4, 1967, pp. 1300–1307. doi:10.1063/1.1712084

Cohen, E. Richard, David R. Lide, and George L. Trigg, editors. AlP Physics Desk Reference, 3rd edition. New York: Springer-Verlag New York, Inc., 2003.

Connelly, Neil G., Ture Damhus, Richard M. Hartshorn, and Alan T. Hutton. Nomenclature of Inorganic Chemistry: IUPAC Recommendations 2005. Cambridge: RSC Publishing, 2005.

Cordero, Beatriz, Verónica Gómez, Ana E. Platero-Prats, Marc Revés, Jorge Echeverría, Eduard Cremades, Flavia Barragán, and Santiago Alvarez. "Covalent Radii Revisited." Dalton Transactions, number 21, 2008, pp 2832–2838. doi:10.1039/b801115j

Cox, P. A. The Elements: Their Origin, Abundance and Distribution. Oxford: Oxford University Press, 1989.

de Podesta, Michael. Understanding the Properties of Matter, 2nd edition. London: Taylor & Francis, 2002.

Debessai, M., J. J. Hamlin, and J. S. Schilling. "Comparison of the Pressure Dependences of Tc in the Trivalent d-Electron Superconductors Sc, Y, La, and Lu up to Megabar Pressures." Physical Review B, volume 78, number 6, 2008, pp. 064519–1 to 064519–10. doi:10.1103/PhysRevB.78.064519

Dronskowski, Richard. Computational Chemistry of Solid State Materials. Weinheim, Germany: WILEY-VCH Verlag GmbH & Co. KGaA, 2005.

Emsley, John. Nature's Building Blocks: An A-Z Guide to the Elements. Oxford: Oxford University Press, 2003.

Emsley, John. The Elements, 3rd edition. Oxford: Oxford University Press, 1998.

Firestone, Richard B. Table of Isotopes, 8th edition, volume 2. Edited by Virginia S. Shirley, with assistant editors Coral M. Baglin, S. Y. Frank Chu, and Jean Zipkin. New York: John Wiley & Sons, Inc., 1996.

Ghosh, Dulal C., and Kartick Gupta. "A New Scale Of Electronegativity Of 54 Elements Of Periodic Table Based On Polarizability Of Atoms." Journal of Theoretical and Computational Chemistry, volume 5, number 4, 2006, pp. 895–911. doi:10.1142/S0219633606002726

Greenwood, N. N., and A. Earnshaw. Chemistry of the Elements, 2nd edition. Oxford: Butterworth-Heinemann, 1997.

Gwyn Williams. Electron Binding Energies. http://www.jlab.org/~gwyn/ebindene.html. Accessed on April 30, 2010.

Ho, C. Y., R. W. Powell, and P. E. Liley. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 3, supplement 1, 1974, pp. I–1 to I–796.

Horvath, A. L. "Critical Temperature of Elements and the Periodic System." Journal of Chemical Education, volume 50, number 5, 1973, pp. 335–336. doi:10.1021/ed050p335

Hotop, H., and W. C. Lineberger. "Binding Energies in Atomic Negative Ions: II." Journal of Physical and Chemical Reference Data, volume 14, number 3, 1985, pp. 731–750.

Huheey, James E., Ellen A. Keiter, and Richard L Keiter. Inorganic Chemistry: Principles of Structure and Reactivity, 4th edition. New York: HarperCollins College Publishers, 1993.

Ihde, Aaron J. The Development of Modern Chemistry. New York: Dover Publications, Inc., 1984.

Jr., Elbert J. Little,, and Mark M. Jones. "A Complete Table of Electronegativities." Journal of Chemical Education, volume 37, number 5, 1960, pp. 231–233. doi:10.1021/ed037p231

Kaxiras, Efthimios. Atomic and Electronic Structure of Solids. Cambridge: Cambridge University Press, 2003.

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.

Krause, M. O. "Atomic Radiative and Radiationless Yields for K and L Shells." Journal of Physical and Chemical Reference Data, volume 8, number 2, 1979, pp. 307–327.

Liboff, Richard L. Introductory Quantum Mechanics, 3rd edition. Reading, MA: Addison Wesley Longman, Inc., 1998.

Lide, David R., editor. CRC Handbook of Chemistry and Physics, 88th edition. Boca Raton, Florida: Taylor & Francis Group, 2008.

Mann, Joseph B., Terry L. Meek, Eugene T. Knight, Joseph F. Capitani, and Leland C. Allen. "Configuration Energies of the d-Block Elements." Journal of the American Chemical Society, volume 122, number 21, 2000, pp. 5132–5137. doi:10.1021/ja9928677

Manuel, O., editor. Origin of Elements in the Solar System: Implications of Post-1957 Observations. New York: Kluwer Academic Publishers, 2000.

Marshall, James L. Discovery of the Elements: A Search for the Fundamental Principles of the Universe, 2nd edition. Boston, MA: Pearson Custom Publishing, 2002.

Martin, W. C. "Electronic Structure of the Elements." The European Physical Journal C — Particles and Fields, volume 15, number 1–4, 2000, pp. 78–79. doi:10.1007/BF02683401

McDonough, W. F. "Compositional Model for the Earth's Core." pp. 547–568 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Mechtly, Eugene A. "Properties of Materials." pp. 4–1 to 4–33 in Reference Data For Engineers: Radio, Electronics, Computer, and Communications. By Mac E. Van Valkenburg, edited by Wendy M. Middleton. Woburn, MA: Butterworth-Heinemann, 2002. doi:10.1016/B978-075067291-7/50006-6

Miessler, Gary L., and Donald A. Tarr. Inorganic Chemistry, 3rd edition. Upper Saddle River, NJ: Pearson Prentice Hall, 2004.

Moore, Charlotte E. Ionization Potentials and Ionization Limits Derived from the Analyses of Optical Spectra. Washington, D.C.: National Bureau of Standards, 1970.

Nagle, Jeffrey K. "Atomic Polarizability and Electronegativity." Journal of the American Chemical Society, volume 112, number 12, 1990, pp. 4741–4747. doi:10.1021/ja00168a019

Nicholas, J. V., and D. R. White. "Temperature." pp. 8–41 in Measurement of the Thermodynamic Properties of Single Phases. Edited by A. R. H. Goodwin, W. A. Wakeham, and K. N. Marsh. Amsterdam: Elsevier Science, 2003.

Orem, W. H., and R. B. Finkelman. "Coal Formation and Geochemistry." pp. 191–222 in Sediments, Diagenesis, and Sedimentary Rocks. Edited by Fred T. Mackenzie. Oxford: Elsevier Ltd., 2005.

Oxtoby, David W., H. P. Gillis, and Alan Campion. Principles of Modern Chemistry, 6th edition. Belmont, CA: Thomson Brooks/Cole, 2008.

Palme, H., and H. Beer. "Meteorites and the Composition of the Solar Photosphere." pp. 204–206 in Landolt–Börnstein—Group VI: Astronomy and Astrophysics. Edited by H. H. Voigt. New York: Springer–Verlag, 1993. doi:10.1007/10057790_59

Palme, H., and Hugh St. C. O'Neill. "Cosmochemical Estimates of Mantle Composition." pp. 1–38 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Pauling, Linus. The Nature of the Chemical Bond, 3rd edition. Ithaca, NY: Cornell University Press, 1960.

Pearson, Ralph G. "Absolute Electronegativity and Hardness: Application to Inorganic Chemistry." Inorganic Chemistry, volume 27, number 4, 1988, pp 734–740. doi:10.1021/ic00277a030

Pekka Pyykkö. Self-Consistent, Year-2009 Covalent Radii. http://www.chem.helsinki.fi/~pyykko/Radii09.pdf. Accessed on November 20, 2010.

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Double-Bond Covalent Radii for Elements Li-E112." Chemistry - A European Journal, volume 15, number 46, 2009, pp. 12770–12779. doi:10.1002/chem.200901472

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Single-Bond Covalent Radii for Elements 1-118." Chemistry - A European Journal, volume 15, number 1, 2009, pp. 186–197. doi:10.1002/chem.200800987

Pyykkö, Pekka, Sebastian Riedel, and Michael Patzschke. "Triple-Bond Covalent Radii." Chemistry - A European Journal, volume 11, number 12, 2005, pp. 3511–3520. doi:10.1002/chem.200401299

Ringnes, Vivi. "Origin of the Names of Chemical Elements." Journal of Chemical Education, volume 66, number 9, 1989, pp. 731–738. doi:10.1021/ed066p731

Samsonov, G. V., editor. Handbook of the Physicochemical Properties of the Elements. New York: Plenum Publishing Corporation, 1968.

Sansonetti, J. E., and W. C. Martin. "Handbook of Basic Atomic Spectroscopic Data." Journal Of Physical And Chemical Reference Data, volume 34, number 4, 2005, pp. 1559–2259. doi:10.1063/1.1800011

Shannon, R. D. "Revised Effective Ionic Radii and Systematic Studies of Interatomic Distances in Halides and Chalcogenides." Acta Crystallographica Section A, volume 32, number 5, 1976, pp. 751–767. doi:10.1107/S0567739476001551

Silbey, Robert J., Robert A. Alberty, and Moungi G. Bawendi. Physical Chemistry, 4th edition. Hoboken, NJ: John Wiley & Sons, Inc., 2005.

Singman, Charles N. "Atomic Volume and Allotropy of the Elements." Journal of Chemical Education, volume 61, number 2, 1984, pp. 137–142. doi:10.1021/ed061p137

Slater, J. C. "Atomic Radii in Crystals." The Journal of Chemical Physics, volume 41, number 10, 1964, pp. 3199–3204. doi:10.1063/1.1725697

Smith, Derek W. Inorganic Substances: A Prelude to the Study of Descriptive Inorganic Chemistry. Cambridge: Cambridge University Press, 1990.

Stewart, G. R. "Measurement of low-temperature specific heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Stewart, G. R. "Measurement of Low-Temperature Specific Heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Tari, A. The Specific Heat of Matter at Low Temperatures. London: Imperial College Press, 2003.

Vainshtein, Boris K., Vladimir M. Fridkin, and Vladimir L. Indenbom. Structure of Crystals, 2nd edition. Modern Crystallography 2. Edited by Boris K. Vainshtein, A. A. Chernov, and L. A. Shuvalov. Berlin: Springer-Verlag, 1995.

Voigt, H. H., editor. Landolt–Börnstein—Group VI Astronomy and Astrophysics. Berlin: Springer–Verlag, 1993.

Waber, J. T., and Don T. Cromer. "Orbital Radii of Atoms and Ions." Journal of Chemical Physics, volume 42, number 12, 1965, pp. 4116–4123. doi:10.1063/1.1695904

Wagman, Donald D., William H. Evans, Vivian B. Parker, Richard H. Schumm, Iva Halow, Sylvia M. Bailey, Kenneth L. Churney, and Ralph L. Nuttall. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 11, supplement 2, 1982, pp. 2–1 to 2–392.

Waldron, Kimberley A., Erin M. Fehringer, Amy E. Streeb, Jennifer E. Trosky, and Joshua J. Pearson. "Screening Percentages Based on Slater Effective Nuclear Charge as a Versatile Tool for Teaching Periodic Trends." Journal of Chemical Education, volume 78, number 5, 2001, pp. 635–639. doi:10.1021/ed078p635

Weeks, Mary Elvira, and Henry M. Leicester. Discovery of the Elements, 7th edition. Easton, PA: Journal of Chemical Education, 1968.

Wieser, Michael E., and Tyler B. Coplen. "Atomic weights of the elements 2009 (IUPAC Technical Report)." Pure and Applied Chemistry, volume 83, number 2, 2011, pp. 359–396. doi:10.1351/PAC-REP-10-09-14

Yaws, Carl L. "Liquid Density of the Elements." Chemical Engineering, volume 114, number 12, 2007, pp. 44–46.

Yaws, Carl L. The Yaws Handbook of Physical Properties for Hydrocarbons and Chemicals. Houston, TX: Gulf Publishing Company, 2005.
