Gadolinium Quick Reference

Click button to see citations

Notes

Symbol

Gd

Atomic Number

64

Atomic Weight

Rounded

157.3

for regular calculations

Standard

157.25 ± 0.03

for precise calculations

Oxidation States

3

more common with disagreement

2

less common

1

less common

Pauling Electronegativity

1.20

Electron Configuration

Orbital Occupancy

[Xe] 4f7 5d1 6s2

[Xe] represents the closed-shell electron configuration of xenon

Orbital Filling Order

[Xe] 6s2 4f7 5d1

[Xe] represents the closed-shell electron configuration of xenon

Term Symbol

9D2

see expanded configuration ...

Ionization Energies

I   (1)

 6.14980 eV

II  (2)

12.09 eV

III (3)

20.63 ± 0.10 eV

IV  (4)

44.0 ± 0.7 eV

Density

liquid, 1586.15 K

7.400 g/ml

solid, 25 °C

7.900 g/cm3

Molar Volume

solid, 298 K, 1 atm

19.90 cm3/mol

Melting Point

1591 ± 10 K

Boiling Point

1 atm

3546.15 K

Thermal Conductivity

solid

300 K

polycrystalline

10.6 W/(m K)

parallel to c-axis

10.8 W/(m K)

perpendicular to c-axis

10.4 W/(m K)

273.2 K

polycrystalline

10.4 W/(m K)

parallel to c-axis

10.4 W/(m K)

perpendicular to c-axis

10.3 W/(m K)

see all 60 conductivities ...

Pyykkö Covalent Radius

single bond

169 pm

double bond

135 pm

triple bond

132 pm

Atomic Radius

179 pm

Enthalpy of Fusion

1 atm

15.5 kJ/mol

Enthalpy of Vaporization

1 atm

311.7 kJ/mol

Quantity

Gadolinium Atomic Structure

Notes

Ionization Energies

I   (1)

 6.14980 eV

II  (2)

12.09 eV

III (3)

20.63 ± 0.10 eV

IV  (4)

44.0 ± 0.7 eV

Electron Binding Energies

K    (1s)

50239 eV

LI   (2s)

 8376 eV

LII  (2p1/2)

 7930 eV

LIII (2p3/2)

 7243 eV

see all 18 energies ...

Electron Configuration

Orbital Occupancy

[Xe] 4f7 5d1 6s2

[Xe] represents the closed-shell electron configuration of xenon

Orbital Filling Order

[Xe] 6s2 4f7 5d1

[Xe] represents the closed-shell electron configuration of xenon

Term Symbol

9D2

see expanded configuration ...

Clementi-Raimondi Effective Nuclear Charge

1s

Orbital Exponent

62.7435

ζ

Principle Quantum Number

1

n

Effective Nuclear Charge

62.7435

Zeff = ζ × n

2s

Orbital Exponent

23.6085

ζ

Principle Quantum Number

2

n

Effective Nuclear Charge

47.2170

Zeff = ζ × n

see all 13 effective nuclear charges ...

Screening Percentage

91.3%

Fluorescence Yields

ωK

0.932

ωL1

0.102

ωL2

0.175

ωL3

0.167

Coster-Kronig Yields

F12

0.190

F13

0.279

F23

0.15

Quantity

Gadolinium Physical Properties

Notes

Density

liquid, 1586.15 K

7.400 g/ml

solid, 25 °C

7.900 g/cm3

Molar Mass

Rounded

157.3 g/mol

for regular calculations

Standard

157.25 ± 0.03 g/mol

for precise calculations

Molar Volume

solid, 298 K, 1 atm

19.90 cm3/mol

Physical Form

silvery metal

Linear Thermal Expansion Coefficient

100 °C

9.4×10-6 K-1

Speed of Sound

solid, 293 K

2680 m/s

calculated value

Young's Modulus

α-gadolinium

54.8 GPa

Poisson's Ratio

α-gadolinium

0.259

Electrical Resistivity

solid, 295 K

134×10-8 Ohm m

Vickers Hardness

cast, 293 K

510 MN/m2 to 638 MN/m2

annealed, 293 K

559 MN/m2

forged, 293 K

952 MN/m2

Isothermal Bulk Modulus

300 K

38.3 GPa

Isothermal Compressibility

300 K

0.0261 GPa-1

Gram Atomic Volume

20 cm3

Quantity

Gadolinium Atomic Interaction

Notes

Oxidation States

3

more common with disagreement

2

less common

1

less common

Pauling Electronegativity

1.20

Allred-Rochow Electronegativity

1.11

Allred Electronegativity

oxidation state: 2

1.20

Nagle Electronegativity

1.10

Smith Electronegativity

oxidation state: 3

1.25

Cohesive Energy

per mole

400 kJ/mol

per atom

  4.14 eV/atom

Quantity

Gadolinium Thermodynamics

Notes

Melting Point

1591 ± 10 K

Boiling Point

1 atm

3546.15 K

Thermal Conductivity

solid

300 K

polycrystalline

10.6 W/(m K)

parallel to c-axis

10.8 W/(m K)

perpendicular to c-axis

10.4 W/(m K)

273.2 K

polycrystalline

10.4 W/(m K)

parallel to c-axis

10.4 W/(m K)

perpendicular to c-axis

10.3 W/(m K)

see all 60 conductivities ...

Critical Point

8670 K

Vapor Pressure

3262 °C

100 kPa

2703 °C

10 kPa

2300 °C

1 kPa

1994 °C

100 Pa

1755 °C

10 Pa

1563 °C

1 Pa

Curie Point

291.8 K

Enthalpy of Fusion

1 atm

15.5 kJ/mol

Enthalpy of Vaporization

1 atm

311.7 kJ/mol

Isobaric Molar Heat Capacity

298.15 K, 1 bar

37.03 J/(mol K)

Isobaric Specific Heat Capacity

298.15 K, 1 bar

0.236 J/(g K)

Electronic Heat Capacity Coefficient

6.38 mJ/(mol K2)

Debye Temperature

Low Temperature Limit ( 0 K )

182 K

Room Temperature ( 298 K )

155 K

Quantity

Gadolinium Identification

Notes

CAS Number

7440-54-2

Quantity

Gadolinium Atomic Size

Notes

Atomic Radius

179 pm

Orbital Radius

171.3 pm

Pyykkö Covalent Radius

single bond

169 pm

double bond

135 pm

triple bond

132 pm

Cordero Covalent Radius

196 pm

Shannon-Prewitt Crystal Radius

ion charge: +3

coordination number: 6

107.8 pm

coordination number: 7

114 pm

coordination number: 8

119.3 pm

coordination number: 9

124.7 pm

Shannon-Prewitt Effective Ionic Radius

ion charge: +3

coordination number: 6

 93.8 pm

coordination number: 7

100 pm

coordination number: 8

105.3 pm

coordination number: 9

110.7 pm

Pauling Empirical Crystal Radius

ion charge: +3

102 pm

Slater Atomic-Ionic Radius

180 pm

Quantity

Gadolinium Crystal Structure

Notes

Allotropes

allotrope

α-gadolinium

symbol

αGd

allotrope

β-gadolinium

symbol

βGd

allotrope

γ-gadolinium

symbol

γGd

Nearest Neighbor Distance

300 K, 1 atm

358 pm

Atomic Concentration

300 K, 1 atm

3.02×1022 cm-3

Quantity

Gadolinium History

Notes

Discovery

date of discovery

1880

discoverer

Jean-Charles Galissard de Marignac

birth

April 24, 1817

death

April 15, 1894

location of discovery

Geneva, Switzerland

Origin of Element Name

origin

Johan Gadolin

origin description

person—Finnish chemist

Origin of Element Symbol

symbol: Gd

origin

gadolinium

origin description

element name

Quantity

Gadolinium Abundances

Notes

Earth's Crust

6.2 ppm

Earth's Mantle

571 ppb

primitive mantle

Bulk Earth

0.37 ppm

Ocean Water

7×10-7 ppm

Metalliferous Ocean Sediment

Basal

22.6 ppm

Ridge

6 ppm

U.S. Coal

1.8 ppm

estimated from USGS and literature data

Ferns

0.06 ppm to 0.5 ppm

Fungi

0.3 ppm

Solar System

0.3300

number of atoms for every 106 atoms of silicon

Sun

1.12 ± 0.04

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Meteorites

1.08 ± 0.02

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Quantity

Gadolinium Nomenclature

Notes

Element Names in Other Languages

French

gadolinium

German

Gadolinium

Italian

gadolinio

Spanish

gadolinio

Portuguese

gadolíneo

Anions or Anionic Substituent Groups

gadolinide

Cations or Cationic Substituent Groups

gadolinium

Ligands

gadolinido

Heteroatomic Anion

gadolinate

'a' Term—Substitutive Nomenclature

gadolina

'y' Term—Chains and Rings Nomenclature

gadoliny

References    (Click the button next to a value above to see complete citation information for that entry)

Allred, A. L. "Electronegativity Values from Thermochemical Data." Journal of Inorganic and Nuclear Chemistry, volume 17, number 3-4, 1961, pp. 215–221. doi:10.1016/0022-1902(61)80142-5

Anders, Edward, and Nicolas Grevesse. "Abundances of the Elements: Meteoritic and Solar." Geochimica et Cosmochimica Acta, volume 53, number 1, 1989, pp. 197–214. doi:10.1016/0016-7037(89)90286-X

Ball, David W. "Elemental Etymology: What's in a Name?" Journal of Chemical Education, volume 62, number 9, 1985, pp. 787–788. doi:10.1021/ed062p787

Bowen, H. J. M. Environmental Chemistry of the Elements. London: Academic Press, Inc., 1979.

Campbell, J. L. "Fluorescence Yields and Coster–Kronig Probabilities for the Atomic L Subshells. Part II: The L1 Subshell Revisited." Atomic Data and Nuclear Data Tables, volume 95, number 1, 2009, pp. 115–124. doi:10.1016/j.adt.2008.08.002

Campbell, J. L. "Fluorescence Yields and Coster–Kronig Probabilities for the Atomic L Subshells." Atomic Data and Nuclear Data Tables, volume 85, number 2, 2003, pp. 291–315. doi:10.1016/S0092-640X(03)00059-7

Cardarelli, François. Materials Handbook: A Concise Desktop Reference, 2nd edition. London: Springer–Verlag, 2008.

Clementi, E., D. L. Raimondi, and W. P. Reinhardt. "Atomic Screening Constants from SCF Functions. II. Atoms with 37 to 86 Electrons." Journal of Chemical Physics, volume 47, number 4, 1967, pp. 1300–1307. doi:10.1063/1.1712084

Cohen, E. Richard, David R. Lide, and George L. Trigg, editors. AlP Physics Desk Reference, 3rd edition. New York: Springer-Verlag New York, Inc., 2003.

Connelly, Neil G., Ture Damhus, Richard M. Hartshorn, and Alan T. Hutton. Nomenclature of Inorganic Chemistry: IUPAC Recommendations 2005. Cambridge: RSC Publishing, 2005.

Cordero, Beatriz, Verónica Gómez, Ana E. Platero-Prats, Marc Revés, Jorge Echeverría, Eduard Cremades, Flavia Barragán, and Santiago Alvarez. "Covalent Radii Revisited." Dalton Transactions, number 21, 2008, pp 2832–2838. doi:10.1039/b801115j

Cox, P. A. The Elements: Their Origin, Abundance and Distribution. Oxford: Oxford University Press, 1989.

de Podesta, Michael. Understanding the Properties of Matter, 2nd edition. London: Taylor & Francis, 2002.

Dronskowski, Richard. Computational Chemistry of Solid State Materials. Weinheim, Germany: WILEY-VCH Verlag GmbH & Co. KGaA, 2005.

Emsley, John. Nature's Building Blocks: An A-Z Guide to the Elements. Oxford: Oxford University Press, 2003.

Emsley, John. The Elements, 3rd edition. Oxford: Oxford University Press, 1998.

Filyand, M. A., and E. I. Semenova. Handbook of the Rare Elements: Radioactive Elements and Rare Earth Elements, volume 3. Translated by Michael E. Alferieff. London: Oldbourne Book Co. Ltd., 1970.

Firestone, Richard B. Table of Isotopes, 8th edition, volume 2. Edited by Virginia S. Shirley, with assistant editors Coral M. Baglin, S. Y. Frank Chu, and Jean Zipkin. New York: John Wiley & Sons, Inc., 1996.

Greenwood, N. N., and A. Earnshaw. Chemistry of the Elements, 2nd edition. Oxford: Butterworth-Heinemann, 1997.

Gwyn Williams. Electron Binding Energies. http://www.jlab.org/~gwyn/ebindene.html. Accessed on April 30, 2010.

Ho, C. Y., R. W. Powell, and P. E. Liley. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 3, supplement 1, 1974, pp. I–1 to I–796.

Horvath, A. L. "Critical Temperature of Elements and the Periodic System." Journal of Chemical Education, volume 50, number 5, 1973, pp. 335–336. doi:10.1021/ed050p335

Huheey, James E., Ellen A. Keiter, and Richard L Keiter. Inorganic Chemistry: Principles of Structure and Reactivity, 4th edition. New York: HarperCollins College Publishers, 1993.

Ihde, Aaron J. The Development of Modern Chemistry. New York: Dover Publications, Inc., 1984.

Jr., Elbert J. Little,, and Mark M. Jones. "A Complete Table of Electronegativities." Journal of Chemical Education, volume 37, number 5, 1960, pp. 231–233. doi:10.1021/ed037p231

King, H. W. "Pressure-Dependent Allotropic Structures of the Elements." Bulletin of Alloy Phase Diagrams, volume 4, number 4, 1983, pp. 449–450. doi:10.1007/BF02868110

King, H. W. "Temperature-Dependent Allotropic Structures of the Elements." Bulletin of Alloy Phase Diagrams, volume 3, number 2, 1982, pp. 275–276. doi:10.1007/BF02892394

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.

Konings, Rudy J. M., and Ondrej Beneš. "The Thermodynamic Properties of the f-Elements and Their Compounds. I. The Lanthanide and Actinide Metals." Journal of Physical and Chemical Reference Data, volume 39, number 4, 2010, pp. 043102–1 to 043102–47. doi:10.1063/1.3474238

Li, Y.-H., and J. E. Schoonmaker. "Chemical Composition and Mineralogy of Marine Sediments." pp. 1–36 in Sediments, Diagenesis, and Sedimentary Rocks. Edited by Fred T. Mackenzie. Oxford: Elsevier Ltd., 2005.

Liboff, Richard L. Introductory Quantum Mechanics, 3rd edition. Reading, MA: Addison Wesley Longman, Inc., 1998.

Lide, David R., editor. CRC Handbook of Chemistry and Physics, 88th edition. Boca Raton, Florida: Taylor & Francis Group, 2008.

Manuel, O., editor. Origin of Elements in the Solar System: Implications of Post-1957 Observations. New York: Kluwer Academic Publishers, 2000.

Marshall, James L. Discovery of the Elements: A Search for the Fundamental Principles of the Universe, 2nd edition. Boston, MA: Pearson Custom Publishing, 2002.

Martin, W. C. "Electronic Structure of the Elements." The European Physical Journal C — Particles and Fields, volume 15, number 1–4, 2000, pp. 78–79. doi:10.1007/BF02683401

Martin, W. C., Romuald Zalubas, and Lucy Hagan. Atomic Energy Levels—The Rare-Earth Elements. Washington, D.C.: National Bureau of Standards, 1978.

McDonough, W. F. "Compositional Model for the Earth's Core." pp. 547–568 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Mechtly, Eugene A. "Properties of Materials." pp. 4–1 to 4–33 in Reference Data For Engineers: Radio, Electronics, Computer, and Communications. By Mac E. Van Valkenburg, edited by Wendy M. Middleton. Woburn, MA: Butterworth-Heinemann, 2002. doi:10.1016/B978-075067291-7/50006-6

Miessler, Gary L., and Donald A. Tarr. Inorganic Chemistry, 3rd edition. Upper Saddle River, NJ: Pearson Prentice Hall, 2004.

Nagle, Jeffrey K. "Atomic Polarizability and Electronegativity." Journal of the American Chemical Society, volume 112, number 12, 1990, pp. 4741–4747. doi:10.1021/ja00168a019

Orem, W. H., and R. B. Finkelman. "Coal Formation and Geochemistry." pp. 191–222 in Sediments, Diagenesis, and Sedimentary Rocks. Edited by Fred T. Mackenzie. Oxford: Elsevier Ltd., 2005.

Oxtoby, David W., H. P. Gillis, and Alan Campion. Principles of Modern Chemistry, 6th edition. Belmont, CA: Thomson Brooks/Cole, 2008.

Palme, H., and H. Beer. "Meteorites and the Composition of the Solar Photosphere." pp. 204–206 in Landolt–Börnstein—Group VI: Astronomy and Astrophysics. Edited by H. H. Voigt. New York: Springer–Verlag, 1993. doi:10.1007/10057790_59

Palme, H., and Hugh St. C. O'Neill. "Cosmochemical Estimates of Mantle Composition." pp. 1–38 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Pauling, Linus. The Nature of the Chemical Bond, 3rd edition. Ithaca, NY: Cornell University Press, 1960.

Pekka Pyykkö. Self-Consistent, Year-2009 Covalent Radii. http://www.chem.helsinki.fi/~pyykko/Radii09.pdf. Accessed on November 20, 2010.

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Double-Bond Covalent Radii for Elements Li-E112." Chemistry - A European Journal, volume 15, number 46, 2009, pp. 12770–12779. doi:10.1002/chem.200901472

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Single-Bond Covalent Radii for Elements 1-118." Chemistry - A European Journal, volume 15, number 1, 2009, pp. 186–197. doi:10.1002/chem.200800987

Pyykkö, Pekka, Sebastian Riedel, and Michael Patzschke. "Triple-Bond Covalent Radii." Chemistry - A European Journal, volume 11, number 12, 2005, pp. 3511–3520. doi:10.1002/chem.200401299

Rayner-Canham, Geoff, and Zheng Zheng. "Naming Elements after Scientists: an Account of a Controversy." Foundations of Chemistry, volume 10, number 1, 2008, pp. 13–18. doi:10.1007/s10698-007-9042-1

Rohrer, Gregory S. Structure and Bonding in Crystalline Materials. Cambridge: Cambridge University Press, 2001.

Samsonov, G. V., editor. Handbook of the Physicochemical Properties of the Elements. New York: Plenum Publishing Corporation, 1968.

Sansonetti, J. E., and W. C. Martin. "Handbook of Basic Atomic Spectroscopic Data." Journal Of Physical And Chemical Reference Data, volume 34, number 4, 2005, pp. 1559–2259. doi:10.1063/1.1800011

Scientific Group Thermodata Europe (SGTE). Pure Substances: Part 1—Elements and Compounds from AgBr to Ba3N2. Edited by I. Hurtado and D. Neuschütz. Berlin: Springer-Verlag, 1999. doi:10.1007/10652891_3

Shannon, R. D. "Revised Effective Ionic Radii and Systematic Studies of Interatomic Distances in Halides and Chalcogenides." Acta Crystallographica Section A, volume 32, number 5, 1976, pp. 751–767. doi:10.1107/S0567739476001551

Silbey, Robert J., Robert A. Alberty, and Moungi G. Bawendi. Physical Chemistry, 4th edition. Hoboken, NJ: John Wiley & Sons, Inc., 2005.

Singman, Charles N. "Atomic Volume and Allotropy of the Elements." Journal of Chemical Education, volume 61, number 2, 1984, pp. 137–142. doi:10.1021/ed061p137

Slater, J. C. "Atomic Radii in Crystals." The Journal of Chemical Physics, volume 41, number 10, 1964, pp. 3199–3204. doi:10.1063/1.1725697

Smith, Derek W. "Electronegativity in Two Dimensions: Reassessment and Resolution of the Pearson-Pauling Paradox." Journal of Chemical Education, volume 67, number 11, 1990, pp. 911–914. doi:10.1021/ed067p911

Smith, Derek W. Inorganic Substances: A Prelude to the Study of Descriptive Inorganic Chemistry. Cambridge: Cambridge University Press, 1990.

Stewart, G. R. "Measurement of low-temperature specific heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Stewart, G. R. "Measurement of Low-Temperature Specific Heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Tari, A. The Specific Heat of Matter at Low Temperatures. London: Imperial College Press, 2003.

Vainshtein, Boris K., Vladimir M. Fridkin, and Vladimir L. Indenbom. Structure of Crystals, 2nd edition. Modern Crystallography 2. Edited by Boris K. Vainshtein, A. A. Chernov, and L. A. Shuvalov. Berlin: Springer-Verlag, 1995.

Voigt, H. H., editor. Landolt–Börnstein—Group VI Astronomy and Astrophysics. Berlin: Springer–Verlag, 1993.

Waber, J. T., and Don T. Cromer. "Orbital Radii of Atoms and Ions." Journal of Chemical Physics, volume 42, number 12, 1965, pp. 4116–4123. doi:10.1063/1.1695904

Wagman, Donald D., William H. Evans, Vivian B. Parker, Richard H. Schumm, Iva Halow, Sylvia M. Bailey, Kenneth L. Churney, and Ralph L. Nuttall. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 11, supplement 2, 1982, pp. 2–1 to 2–392.

Waldron, Kimberley A., Erin M. Fehringer, Amy E. Streeb, Jennifer E. Trosky, and Joshua J. Pearson. "Screening Percentages Based on Slater Effective Nuclear Charge as a Versatile Tool for Teaching Periodic Trends." Journal of Chemical Education, volume 78, number 5, 2001, pp. 635–639. doi:10.1021/ed078p635

Weeks, Mary Elvira, and Henry M. Leicester. Discovery of the Elements, 7th edition. Easton, PA: Journal of Chemical Education, 1968.

Wieser, Michael E., and Tyler B. Coplen. "Atomic weights of the elements 2009 (IUPAC Technical Report)." Pure and Applied Chemistry, volume 83, number 2, 2011, pp. 359–396. doi:10.1351/PAC-REP-10-09-14

Yaws, Carl L. "Liquid Density of the Elements." Chemical Engineering, volume 114, number 12, 2007, pp. 44–46.

Yaws, Carl L. The Yaws Handbook of Physical Properties for Hydrocarbons and Chemicals. Houston, TX: Gulf Publishing Company, 2005.
