Zirconium Quick Reference

Click button to see citations

Notes

Symbol

Zr

Atomic Number

40

Atomic Weight

Rounded

91.22

for regular calculations

Standard

91.224 ± 0.002

for precise calculations

Oxidation States

 4

more common

 3

less common with disagreement

 2

less common

 1

less common

 0

less common

-2

less common

Pauling Electronegativity

oxidation state: 2

1.33

Electron Configuration

Orbital Occupancy

[Kr] 4d2 5s2

[Kr] represents the closed-shell electron configuration of krypton

Orbital Filling Order

[Kr] 5s2 4d2

[Kr] represents the closed-shell electron configuration of krypton

Term Symbol

3F2

see expanded configuration ...

Ionization Energies

I   (1)

 6.63390 eV

II  (2)

13.1 eV

III (3)

22.99 eV

IV  (4)

34.34 eV

V   (5)

80.348 eV

Electron Affinity

0.426 ± 0.014 eV

 3440 ± 110 cm-1

Density

liquid, 2128.15 K

5.800 g/ml

solid, 25 °C

6.520 g/cm3

Molar Volume

solid, 298 K, 1 atm

14.024 cm3/mol

Melting Point

1 atm

2127 K

ITS-90 second-quality, secondary reference point (melting point)

Boiling Point

1 atm

4682.15 K

Thermal Conductivity

solid

400 K, polycrystalline

21.6 W/(m K)

300 K, polycrystalline

22.7 W/(m K)

273.2 K, polycrystalline

23.2 W/(m K)

extrapolated or interpolated

200 K, polycrystalline

25.2 W/(m K)

extrapolated or interpolated

see all 45 conductivities ...

Pyykkö Covalent Radius

single bond

154 pm

double bond

127 pm

triple bond

121 pm

Atomic Radius

160 pm

Enthalpy of Fusion

1 atm

23 kJ/mol

Enthalpy of Vaporization

1 atm

581.6 kJ/mol

Quantity

Zirconium Atomic Structure

Notes

Ionization Energies

I   (1)

 6.63390 eV

II  (2)

13.1 eV

III (3)

22.99 eV

IV  (4)

34.34 eV

V   (5)

80.348 eV

Electron Affinity

0.426 ± 0.014 eV

 3440 ± 110 cm-1

Electron Binding Energies

K    (1s)

17998 eV

LI   (2s)

 2532 eV

LII  (2p1/2)

 2307 eV

LIII (2p3/2)

 2223 eV

see all 12 energies ...

Electron Configuration

Orbital Occupancy

[Kr] 4d2 5s2

[Kr] represents the closed-shell electron configuration of krypton

Orbital Filling Order

[Kr] 5s2 4d2

[Kr] represents the closed-shell electron configuration of krypton

Term Symbol

3F2

see expanded configuration ...

Clementi-Raimondi Effective Nuclear Charge

1s

Orbital Exponent

39.1590

ζ

Principle Quantum Number

1

n

Effective Nuclear Charge

39.1590

Zeff = ζ × n

2s

Orbital Exponent

14.6869

ζ

Principle Quantum Number

2

n

Effective Nuclear Charge

29.3738

Zeff = ζ × n

see all 10 effective nuclear charges ...

Screening Percentage

90.4%

Fluorescence Yields

ωK

0.734

ωL1

0.0068

ωL2

0.028

ωL3

0.031

Coster-Kronig Yields

F12

0.26

F13

0.57

F23

0.1

Quantity

Zirconium Physical Properties

Notes

Density

liquid, 2128.15 K

5.800 g/ml

solid, 25 °C

6.520 g/cm3

Molar Mass

Rounded

91.22 g/mol

for regular calculations

Standard

91.224 ± 0.002 g/mol

for precise calculations

Molar Volume

solid, 298 K, 1 atm

14.024 cm3/mol

Physical Form

gray-white metal

Linear Thermal Expansion Coefficient

25 °C

5.7×10-6 K-1

Speed of Sound

solid, 20 °C

longitudinal wave

4650 m/s

shear wave

2250 m/s

Specific Gravity

68 °F, water at 4 °C (39.2 °F)

6.51

Young's Modulus

97.1 GPa

Poisson's Ratio

0.380

Electrical Resistivity

α-zirconium, solid

200 K

26.33×10-8 Ohm m

273 K

38.8×10-8 Ohm m

293 K

42.1×10-8 Ohm m

300 K

43.3×10-8 Ohm m

400 K

60.3×10-8 Ohm m

see all 45 resistivities ...

Contact Potential

3.60 eV

Photoelectric Work Function

3.82 eV

Thermionic Work Function

4.21 eV

Superconducting Transition Temperature

ambient pressure

 0.546 K

30 GPa

11 K

maximum temperature

0 Pa

 0.546 K

Superconducting Critical Magnetic Field at Absolute Zero

47×10-4 T

Mineralogical Hardness

5.0

Vickers Hardness

iodide, purity - 99.99%

293 K

903 MN/m2

473 K

540 MN/m2

873 K

235 MN/m2

Isothermal Bulk Modulus

300 K

83.3 GPa

Isothermal Compressibility

300 K

0.0120 GPa-1

Gram Atomic Volume

14 cm3

Quantity

Zirconium Atomic Interaction

Notes

Oxidation States

 4

more common

 3

less common with disagreement

 2

less common

 1

less common

 0

less common

-2

less common

Pauling Electronegativity

oxidation state: 2

1.33

Sanderson Electronegativity

oxidation state: 4

0.90

oxidation state: 3

0.79

oxidation state: 2

0.52

Allred-Rochow Electronegativity

oxidation state: 4

1.22

Configuration Energy

electron volt units

7.808 eV

Pauling units

1.32

Allred Electronegativity

oxidation state: 2

1.33

Ghosh-Gupta Electronegativity

2.8489 eV

Nagle Electronegativity

1.17

Pearson Absolute Electronegativity

3.64 eV

Smith Electronegativity

oxidation state: 4

1.5

Chemical Hardness

3.21 eV

Cohesive Energy

per mole

603 kJ/mol

per atom

  6.25 eV/atom

Quantity

Zirconium Thermodynamics

Notes

Melting Point

1 atm

2127 K

ITS-90 second-quality, secondary reference point (melting point)

Boiling Point

1 atm

4682.15 K

Thermal Conductivity

solid

400 K, polycrystalline

21.6 W/(m K)

300 K, polycrystalline

22.7 W/(m K)

273.2 K, polycrystalline

23.2 W/(m K)

extrapolated or interpolated

200 K, polycrystalline

25.2 W/(m K)

extrapolated or interpolated

see all 45 conductivities ...

Critical Point

8650 K

Vapor Pressure

4405 °C

100 kPa

3780 °C

10 kPa

3302 °C

1 kPa

2924 °C

100 Pa

2618 °C

10 Pa

2366 °C

1 Pa

Enthalpy of Fusion

1 atm

23 kJ/mol

Enthalpy of Vaporization

1 atm

581.6 kJ/mol

Isobaric Molar Heat Capacity

298.15 K, 1 bar

25.36 J/(mol K)

Isobaric Specific Heat Capacity

298.15 K, 1 bar

0.278 J/(g K)

Electronic Heat Capacity Coefficient

2.77 mJ/(mol K2)

Debye Temperature

Low Temperature Limit ( 0 K )

290 K

Room Temperature ( 298 K )

250 K

Quantity

Zirconium Identification

Notes

CAS Number

7440-67-7

DOT Number

dry, coiled wire, finished metal sheets or strips

2858

dry, finished sheets, strips or coiled wire

2009

powder, dry

2008

scrap

1932

ICSC Number

unstable powder

1405

RTECS Number

ZH7070000

UN Number

unstable powder

2008

Quantity

Zirconium Atomic Size

Notes

Atomic Radius

160 pm

Orbital Radius

159.3 pm

Pyykkö Covalent Radius

single bond

154 pm

double bond

127 pm

triple bond

121 pm

Cordero Covalent Radius

175 pm

Shannon-Prewitt Crystal Radius

ion charge: +4

coordination number: 4

 73 pm

coordination number: 5

 80 pm

coordination number: 6

 86 pm

coordination number: 7

 92 pm

coordination number: 8

 98 pm

coordination number: 9

103 pm

Shannon-Prewitt Effective Ionic Radius

ion charge: +4

coordination number: 4

59 pm

coordination number: 5

66 pm

coordination number: 6

72 pm

coordination number: 7

78 pm

coordination number: 8

84 pm

coordination number: 9

89 pm

Pauling Empirical Crystal Radius

ion charge: +4

80 pm

Pauling Univalent Radius

ion charge: +1

109 pm

Batsanov Crystallographic Van Der Waals Radius

2.3×102 pm

Batsanov Equilibrium Van Der Waals Radius

257 pm

Slater Atomic-Ionic Radius

155 pm

Quantity

Zirconium Crystal Structure

Notes

Allotropes

allotrope

α-zirconium

symbol

αZr

allotrope

β-zirconium

symbol

βZr

allotrope

ω-zirconium

symbol

ωZr

Nearest Neighbor Distance

300 K, 1 atm

317 pm

Atomic Concentration

300 K, 1 atm

4.29×1022 cm-3

Quantity

Zirconium History

Notes

Discovery

date of discovery

1789

discoverer

Martin Heinrich Klaproth

birth

December 1, 1743

death

January 1, 1817

location of discovery

Berlin, Germany

Origin of Element Name

origin

zargun

origin description

color—Arabic for gold colored

Origin of Element Symbol

symbol: Zr

origin

zirconium

origin description

element name

Quantity

Zirconium Abundances

Notes

Earth's Crust

1.65×102 ppm

Earth's Mantle

10.81 ppm

primitive mantle

Bulk Earth

7.1 ppm

Ocean Water

2.6×10-6 ppm

Metalliferous Ocean Sediment

Basal

225 ppm

River Water

0.003 ppm

U.S. Coal

27 ppm

Human Body

1 mg

based on a 70 kg "reference man"

Human Bone

<0.1 ppm

Human Hair

1.4 ppm

Human Kidney

0.066 ppm to 0.09 ppm

Human Liver

0.11 ppm

Human Muscle

0.08 ppm

Human Nail

1.4 ppm

Bacteria

20 ppm

Ferns

2.3 ppm

Solar System

11.4

number of atoms for every 106 atoms of silicon

Sun

2.60 ± 0.02

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Meteorites

2.60 ± 0.02

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Quantity

Zirconium Nomenclature

Notes

Element Names in Other Languages

French

zirconium

German

Zirkonium

Italian

zirconio

Spanish

circonio

Portuguese

zircónio

Anions or Anionic Substituent Groups

zirconide

Cations or Cationic Substituent Groups

zirconium

Ligands

zirconido

Heteroatomic Anion

zirconate

'a' Term—Substitutive Nomenclature

zircona

'y' Term—Chains and Rings Nomenclature

zircony

References    (Click the button next to a value above to see complete citation information for that entry)

Allred, A. L. "Electronegativity Values from Thermochemical Data." Journal of Inorganic and Nuclear Chemistry, volume 17, number 3-4, 1961, pp. 215–221. doi:10.1016/0022-1902(61)80142-5

Anders, Edward, and Nicolas Grevesse. "Abundances of the Elements: Meteoritic and Solar." Geochimica et Cosmochimica Acta, volume 53, number 1, 1989, pp. 197–214. doi:10.1016/0016-7037(89)90286-X

Andersen, T., H. K. Haugen, and H. Hotop. "Binding Energies in Atomic Negative Ions: III." Journal of Physical and Chemical Reference Data, volume 28, number 6, 1999, pp. 1511–1533.

Ball, David W. "Elemental Etymology: What's in a Name?" Journal of Chemical Education, volume 62, number 9, 1985, pp. 787–788. doi:10.1021/ed062p787

Barsan, Michael E., editor. NIOSH Pocket Guide to Chemical Hazards. Cincinnati, Ohio: NIOSH Publications, 2007.

Batsanov, S. S. "Van der Waals Radii of Elements." Inorganic Materials, volume 37, number 9, 2001, pp. 871–885. See abstract

Bedford, R. E., G. Bonnier, H. Maas, and F. Pavese. "Recommended Values of Temperature on the International Temperature Scale of 1990 for a Selected Set of Secondary Reference Points." Metrologia, volume 33, number 2, 1996, pp. 133–154. doi:10.1088/0026-1394/33/2/3

Bowen, H. J. M. Environmental Chemistry of the Elements. London: Academic Press, Inc., 1979.

Campbell, J. L. "Fluorescence Yields and Coster–Kronig Probabilities for the Atomic L Subshells." Atomic Data and Nuclear Data Tables, volume 85, number 2, 2003, pp. 291–315. doi:10.1016/S0092-640X(03)00059-7

Cardarelli, François. Materials Handbook: A Concise Desktop Reference, 2nd edition. London: Springer–Verlag, 2008.

Clementi, E., D. L. Raimondi, and W. P. Reinhardt. "Atomic Screening Constants from SCF Functions. II. Atoms with 37 to 86 Electrons." Journal of Chemical Physics, volume 47, number 4, 1967, pp. 1300–1307. doi:10.1063/1.1712084

Cohen, E. Richard, David R. Lide, and George L. Trigg, editors. AlP Physics Desk Reference, 3rd edition. New York: Springer-Verlag New York, Inc., 2003.

Connelly, Neil G., Ture Damhus, Richard M. Hartshorn, and Alan T. Hutton. Nomenclature of Inorganic Chemistry: IUPAC Recommendations 2005. Cambridge: RSC Publishing, 2005.

Cordero, Beatriz, Verónica Gómez, Ana E. Platero-Prats, Marc Revés, Jorge Echeverría, Eduard Cremades, Flavia Barragán, and Santiago Alvarez. "Covalent Radii Revisited." Dalton Transactions, number 21, 2008, pp 2832–2838. doi:10.1039/b801115j

Cronan, D. S. "Basal Metalliferous Sediments from the Eastern Pacific." Geological Society of America Bulletin, volume 87, number 6, 1976, pp. 928–934. doi:10.1130/0016-7606(1976)87<928:BMSFTE>2.0.CO;2

de Podesta, Michael. Understanding the Properties of Matter, 2nd edition. London: Taylor & Francis, 2002.

Debessai, M., J. J. Hamlin, and J. S. Schilling. "Comparison of the Pressure Dependences of Tc in the Trivalent d-Electron Superconductors Sc, Y, La, and Lu up to Megabar Pressures." Physical Review B, volume 78, number 6, 2008, pp. 064519–1 to 064519–10. doi:10.1103/PhysRevB.78.064519

Desai, P. D., H. M. James, and C. Y. Ho. "Electrical Resistivity of Vanadium and Zirconium." Journal of Physical and Chemical Reference Data, volume 13, number 4, 1984, pp. 1097–1130.

Dronskowski, Richard. Computational Chemistry of Solid State Materials. Weinheim, Germany: WILEY-VCH Verlag GmbH & Co. KGaA, 2005.

Emsley, John. Nature's Building Blocks: An A-Z Guide to the Elements. Oxford: Oxford University Press, 2003.

Emsley, John. The Elements, 3rd edition. Oxford: Oxford University Press, 1998.

Firestone, Richard B. Table of Isotopes, 8th edition, volume 2. Edited by Virginia S. Shirley, with assistant editors Coral M. Baglin, S. Y. Frank Chu, and Jean Zipkin. New York: John Wiley & Sons, Inc., 1996.

Galasso, Francis S. Structure and Properties of Inorganic Solids. Oxford: Pergamon Press, 1970.

Ghosh, Dulal C., and Kartick Gupta. "A New Scale Of Electronegativity Of 54 Elements Of Periodic Table Based On Polarizability Of Atoms." Journal of Theoretical and Computational Chemistry, volume 5, number 4, 2006, pp. 895–911. doi:10.1142/S0219633606002726

Greenwood, N. N., and A. Earnshaw. Chemistry of the Elements, 2nd edition. Oxford: Butterworth-Heinemann, 1997.

Gwyn Williams. Electron Binding Energies. http://www.jlab.org/~gwyn/ebindene.html. Accessed on April 30, 2010.

Ho, C. Y., R. W. Powell, and P. E. Liley. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 3, supplement 1, 1974, pp. I–1 to I–796.

Horvath, A. L. "Critical Temperature of Elements and the Periodic System." Journal of Chemical Education, volume 50, number 5, 1973, pp. 335–336. doi:10.1021/ed050p335

Huheey, James E., Ellen A. Keiter, and Richard L Keiter. Inorganic Chemistry: Principles of Structure and Reactivity, 4th edition. New York: HarperCollins College Publishers, 1993.

Ihde, Aaron J. The Development of Modern Chemistry. New York: Dover Publications, Inc., 1984.

International Labour Organization (ILO). International Chemical Safety Card for Zirconium (Unstable Powder). http://www.ilo.org/legacy/english/protection/safework/cis/products/icsc/dtasht/_icsc14/icsc1405.htm. Accessed on May 4, 2010.

International Labour Organization (ILO). International Chemical Safety Card for Zirconium (Unstable Powder). http://www.ilo.org/legacy/english/protection/safework/cis/products/icsc/dtasht/_icsc14/icsc1405.htm. Accessed on May 5, 2010.

Jr., Elbert J. Little,, and Mark M. Jones. "A Complete Table of Electronegativities." Journal of Chemical Education, volume 37, number 5, 1960, pp. 231–233. doi:10.1021/ed037p231

Kaxiras, Efthimios. Atomic and Electronic Structure of Solids. Cambridge: Cambridge University Press, 2003.

King, H. W. "Pressure-Dependent Allotropic Structures of the Elements." Bulletin of Alloy Phase Diagrams, volume 4, number 4, 1983, pp. 449–450. doi:10.1007/BF02868110

King, H. W. "Temperature-Dependent Allotropic Structures of the Elements." Bulletin of Alloy Phase Diagrams, volume 3, number 2, 1982, pp. 275–276. doi:10.1007/BF02892394

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.

Krause, M. O. "Atomic Radiative and Radiationless Yields for K and L Shells." Journal of Physical and Chemical Reference Data, volume 8, number 2, 1979, pp. 307–327.

Li, Y.-H., and J. E. Schoonmaker. "Chemical Composition and Mineralogy of Marine Sediments." pp. 1–36 in Sediments, Diagenesis, and Sedimentary Rocks. Edited by Fred T. Mackenzie. Oxford: Elsevier Ltd., 2005.

Liboff, Richard L. Introductory Quantum Mechanics, 3rd edition. Reading, MA: Addison Wesley Longman, Inc., 1998.

Lide, David R., editor. CRC Handbook of Chemistry and Physics, 88th edition. Boca Raton, Florida: Taylor & Francis Group, 2008.

Mann, Joseph B., Terry L. Meek, Eugene T. Knight, Joseph F. Capitani, and Leland C. Allen. "Configuration Energies of the d-Block Elements." Journal of the American Chemical Society, volume 122, number 21, 2000, pp. 5132–5137. doi:10.1021/ja9928677

Manuel, O., editor. Origin of Elements in the Solar System: Implications of Post-1957 Observations. New York: Kluwer Academic Publishers, 2000.

Marshall, James L. Discovery of the Elements: A Search for the Fundamental Principles of the Universe, 2nd edition. Boston, MA: Pearson Custom Publishing, 2002.

Martin, W. C. "Electronic Structure of the Elements." The European Physical Journal C — Particles and Fields, volume 15, number 1–4, 2000, pp. 78–79. doi:10.1007/BF02683401

McDonough, W. F. "Compositional Model for the Earth's Core." pp. 547–568 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Mechtly, Eugene A. "Properties of Materials." pp. 4–1 to 4–33 in Reference Data For Engineers: Radio, Electronics, Computer, and Communications. By Mac E. Van Valkenburg, edited by Wendy M. Middleton. Woburn, MA: Butterworth-Heinemann, 2002. doi:10.1016/B978-075067291-7/50006-6

Miessler, Gary L., and Donald A. Tarr. Inorganic Chemistry, 3rd edition. Upper Saddle River, NJ: Pearson Prentice Hall, 2004.

Moore, Charlotte E. Ionization Potentials and Ionization Limits Derived from the Analyses of Optical Spectra. Washington, D.C.: National Bureau of Standards, 1970.

Nagle, Jeffrey K. "Atomic Polarizability and Electronegativity." Journal of the American Chemical Society, volume 112, number 12, 1990, pp. 4741–4747. doi:10.1021/ja00168a019

National Institute for Occupational Safety and Health (NIOSH). International Chemical Safety Card for Zirconium (Unstable Powder). http://www.cdc.gov/niosh/ipcsneng/neng1405.html. Accessed on May 4, 2010.

National Institute for Occupational Safety and Health (NIOSH). International Chemical Safety Card for Zirconium (Unstable Powder). http://www.cdc.gov/niosh/ipcsneng/neng1405.html. Accessed on May 5, 2010.

National Institute for Occupational Safety and Health (NIOSH). The Registry of Toxic Effects of Chemical Substances for Zirconium. http://www.cdc.gov/niosh-rtecs/zh6be130.html. Accessed on May 5, 2010.

Nicholas, J. V., and D. R. White. "Temperature." pp. 8–41 in Measurement of the Thermodynamic Properties of Single Phases. Edited by A. R. H. Goodwin, W. A. Wakeham, and K. N. Marsh. Amsterdam: Elsevier Science, 2003.

Orem, W. H., and R. B. Finkelman. "Coal Formation and Geochemistry." pp. 191–222 in Sediments, Diagenesis, and Sedimentary Rocks. Edited by Fred T. Mackenzie. Oxford: Elsevier Ltd., 2005.

Oxtoby, David W., H. P. Gillis, and Alan Campion. Principles of Modern Chemistry, 6th edition. Belmont, CA: Thomson Brooks/Cole, 2008.

Palme, H., and Hugh St. C. O'Neill. "Cosmochemical Estimates of Mantle Composition." pp. 1–38 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Pauling, Linus. The Nature of the Chemical Bond, 3rd edition. Ithaca, NY: Cornell University Press, 1960.

Pearson, Ralph G. "Absolute Electronegativity and Hardness: Application to Inorganic Chemistry." Inorganic Chemistry, volume 27, number 4, 1988, pp 734–740. doi:10.1021/ic00277a030

Pekka Pyykkö. Self-Consistent, Year-2009 Covalent Radii. http://www.chem.helsinki.fi/~pyykko/Radii09.pdf. Accessed on November 20, 2010.

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Double-Bond Covalent Radii for Elements Li-E112." Chemistry - A European Journal, volume 15, number 46, 2009, pp. 12770–12779. doi:10.1002/chem.200901472

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Single-Bond Covalent Radii for Elements 1-118." Chemistry - A European Journal, volume 15, number 1, 2009, pp. 186–197. doi:10.1002/chem.200800987

Pyykkö, Pekka, Sebastian Riedel, and Michael Patzschke. "Triple-Bond Covalent Radii." Chemistry - A European Journal, volume 11, number 12, 2005, pp. 3511–3520. doi:10.1002/chem.200401299

Rohrer, Gregory S. Structure and Bonding in Crystalline Materials. Cambridge: Cambridge University Press, 2001.

Samsonov, G. V., editor. Handbook of the Physicochemical Properties of the Elements. New York: Plenum Publishing Corporation, 1968.

Sanderson, R. T. Simple Inorganic Substances. Malabar, FL: Robert E. Krieger Publishing Co., Inc., 1989.

Sanderson, R. T. "Principles of Electronegativity: Part I. General Nature." Journal of Chemical Education, volume 65, number 2, 1988, pp. 112–118. doi:10.1021/ed065p112

Sansonetti, J. E., and W. C. Martin. "Handbook of Basic Atomic Spectroscopic Data." Journal Of Physical And Chemical Reference Data, volume 34, number 4, 2005, pp. 1559–2259. doi:10.1063/1.1800011

Scientific Group Thermodata Europe (SGTE). Pure Substances: Part 1—Elements and Compounds from AgBr to Ba3N2. Edited by I. Hurtado and D. Neuschütz. Berlin: Springer-Verlag, 1999. doi:10.1007/10652891_3

Shannon, R. D. "Revised Effective Ionic Radii and Systematic Studies of Interatomic Distances in Halides and Chalcogenides." Acta Crystallographica Section A, volume 32, number 5, 1976, pp. 751–767. doi:10.1107/S0567739476001551

Silbey, Robert J., Robert A. Alberty, and Moungi G. Bawendi. Physical Chemistry, 4th edition. Hoboken, NJ: John Wiley & Sons, Inc., 2005.

Singman, Charles N. "Atomic Volume and Allotropy of the Elements." Journal of Chemical Education, volume 61, number 2, 1984, pp. 137–142. doi:10.1021/ed061p137

Slater, J. C. "Atomic Radii in Crystals." The Journal of Chemical Physics, volume 41, number 10, 1964, pp. 3199–3204. doi:10.1063/1.1725697

Smith, Derek W. "Electronegativity in Two Dimensions: Reassessment and Resolution of the Pearson-Pauling Paradox." Journal of Chemical Education, volume 67, number 11, 1990, pp. 911–914. doi:10.1021/ed067p911

Smith, Derek W. Inorganic Substances: A Prelude to the Study of Descriptive Inorganic Chemistry. Cambridge: Cambridge University Press, 1990.

Stewart, G. R. "Measurement of low-temperature specific heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Stewart, G. R. "Measurement of Low-Temperature Specific Heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Tari, A. The Specific Heat of Matter at Low Temperatures. London: Imperial College Press, 2003.

U. S. Department of Transportation (DOT), Transport Canada (TC), Secretariat of Transport and Communications of Mexico (SCT), and Centro de Información Química para Emergencias (CIQUIME). 2008 Emergency Response Guidebook.

Vainshtein, Boris K., Vladimir M. Fridkin, and Vladimir L. Indenbom. Structure of Crystals, 2nd edition. Modern Crystallography 2. Edited by Boris K. Vainshtein, A. A. Chernov, and L. A. Shuvalov. Berlin: Springer-Verlag, 1995.

Voigt, H. H., editor. Landolt–Börnstein—Group VI Astronomy and Astrophysics. Berlin: Springer–Verlag, 1993.

Waber, J. T., and Don T. Cromer. "Orbital Radii of Atoms and Ions." Journal of Chemical Physics, volume 42, number 12, 1965, pp. 4116–4123. doi:10.1063/1.1695904

Wagman, Donald D., William H. Evans, Vivian B. Parker, Richard H. Schumm, Iva Halow, Sylvia M. Bailey, Kenneth L. Churney, and Ralph L. Nuttall. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 11, supplement 2, 1982, pp. 2–1 to 2–392.

Waldron, Kimberley A., Erin M. Fehringer, Amy E. Streeb, Jennifer E. Trosky, and Joshua J. Pearson. "Screening Percentages Based on Slater Effective Nuclear Charge as a Versatile Tool for Teaching Periodic Trends." Journal of Chemical Education, volume 78, number 5, 2001, pp. 635–639. doi:10.1021/ed078p635

Weeks, Mary Elvira, and Henry M. Leicester. Discovery of the Elements, 7th edition. Easton, PA: Journal of Chemical Education, 1968.

Wieser, Michael E., and Tyler B. Coplen. "Atomic weights of the elements 2009 (IUPAC Technical Report)." Pure and Applied Chemistry, volume 83, number 2, 2011, pp. 359–396. doi:10.1351/PAC-REP-10-09-14

Yaws, Carl L. "Liquid Density of the Elements." Chemical Engineering, volume 114, number 12, 2007, pp. 44–46.

Yaws, Carl L. The Yaws Handbook of Physical Properties for Hydrocarbons and Chemicals. Houston, TX: Gulf Publishing Company, 2005.
