Element

Density

Click button to see citations

Notes

Sulfur

liquid, 388.36 K

 1.794 g/ml

cyclo-hexasulfur, solid, 183 K

 2.260 g/cm3

γ–cyclo-heptasulfur, solid, 163 K

 2.190 g/cm3

δ–cyclo-heptasulfur, solid, 163 K

 2.182 g/cm3

α-orthorhombic sulfur, solid

173 K

 2.108 g/cm3

298 K

 2.066 g/cm3

β-monoclinic sulfur, solid

113 K

 2.088 g/cm3

298 K

 2.008 g/cm3

γ-monoclinic sulfur, solid, 298 K

 2.08 g/cm3

α–cyclo-nonasulfur, solid, 173 K

 2.114 g/cm3

cyclo-decasulfur, solid, 163 K

 2.103 g/cm3

the compound S6·S10, solid, 163 K

 2.17 g/cm3

cyclo-undecasulfur, solid, 163 K

 2.08 g/cm3

cyclo-dodecasulfur, solid, 298 K

 2.045 g/cm3

cyclo-tridecasulfur, solid, 173 K

 2.09 g/cm3

cyclo-tetradecasulfur, solid, 173 K

 2.045 g/cm3

α–cyclo-octadecasulfur, solid, 298 K

 2.090 g/cm3

β–cyclo-octadecasulfur, solid, 298 K

 2.009 g/cm3

cyclo-eicosasulfur, solid, 298 K

 2.023 g/cm3

Tantalum

liquid, 3290.15 K

15.000 g/ml

solid, 25 °C

16.400 g/cm3

Technetium

liquid, 2430.15 K

10.615 g/ml

solid, 25 °C

11.000 g/cm3

Tellurium

liquid, 722.66 K

 5.797 g/ml

solid, 25 °C

 6.240 g/cm3

Terbium

liquid, 1629.15 K

 7.650 g/ml

solid, 25 °C

 8.230 g/cm3

Thallium

liquid, 577.15 K

11.291 g/ml

solid, 25 °C

11.800 g/cm3

Thorium

solid, 25 °C

11.700 g/cm3

Thulium

liquid, 1818.15 K

 9.000 g/ml

solid, 25 °C

 9.320 g/cm3

Tin

liquid

1950 K, 1 bar

 6.037 g/ml

1900 K, 1 bar

 6.070 g/ml

1850 K, 1 bar

 6.102 g/ml

1800 K, 1 bar

 6.135 g/ml

1750 K, 1 bar

 6.167 g/ml

1700 K, 1 bar

 6.200 g/ml

1650 K, 1 bar

 6.233 g/ml

1600 K, 1 bar

 6.265 g/ml

1550 K, 1 bar

 6.298 g/ml

1500 K, 1 bar

 6.330 g/ml

1450 K, 1 bar

 6.363 g/ml

1400 K, 1 bar

 6.396 g/ml

1350 K, 1 bar

 6.428 g/ml

1300 K, 1 bar

 6.461 g/ml

1250 K, 1 bar

 6.493 g/ml

1200 K, 1 bar

 6.526 g/ml

1150 K, 1 bar

 6.559 g/ml

1100 K, 1 bar

 6.591 g/ml

1050 K, 1 bar

 6.624 g/ml

1000 K, 1 bar

 6.656 g/ml

950 K, 1 bar

 6.689 g/ml

900 K, 1 bar

 6.722 g/ml

850 K, 1 bar

 6.754 g/ml

800 K, 1 bar

 6.787 g/ml

750 K, 1 bar

 6.819 g/ml

700 K, 1 bar

 6.852 g/ml

650 K, 1 bar

 6.885 g/ml

600 K, 1 bar

 6.917 g/ml

550 K, 1 bar

 6.950 g/ml

506 K, 1 bar

 6.978 g/ml

505 K

 6.980 g/ml

solid

505 K

 7.182 g/cm3

500 K

 7.185 g/cm3

400 K

 7.234 g/cm3

300 K

 7.283 g/cm3

200 K

 7.331 g/cm3

100 K

 7.375 g/cm3

0 K

 7.418 g/cm3

gray tin, solid, 18 °C

 7.285 g/cm3

Titanium

15500 K, 0.7 GPa

 0.5 g/cm3

critical point, predicted for the vapor and the insulating liquid region

liquid, 1941.15 K

 4.110 g/ml

solid, 25 °C

 4.506 g/cm3

Tungsten

22500 K, 1.6 GPa

 3.0 g/cm3

critical point, predicted

liquid, 3695.15 K

17.700 g/ml

α-tungsten, solid

25 °C

19.246 ± 0.003 g/cm3

calculated using x-ray lattice parameter measurements

20 °C

19.250 ± 0.004 g/cm3

hydrostatic weighing, zone refined single crystals

77 K

19.316 g/cm3

calculated using x-ray lattice parameter measurements

Uranium

liquid, 1408.15 K

17.907 g/ml

solid, 25 °C

19.100 g/cm3

Vanadium

liquid, 2183.15 K

 5.550 g/ml

solid, 25 °C

 6.000 g/cm3

Xenon

289.765 ± 0.025 K, 5.8405 ± 0.0005 MPa

 1.113 ± 0.003 g/cm3

critical point, estimated

gas

800 K
1 atm

 2.00 g/L
1 bar

 1.97 g/L

750.000 K
1 atm

 2.13 g/L
1 bar

 2.11 g/L

700.000 K
1 atm

 2.29 g/L
1 bar

 2.26 g/L

650.000 K
1 atm

 2.46 g/L
1 bar

 2.43 g/L

600.000 K
1 atm

 2.67 g/L
1 bar

 2.63 g/L

550.000 K
1 atm

 2.91 g/L
1 bar

 2.87 g/L

500.000 K
1 atm

 3.20 g/L
1 bar

 3.16 g/L

450.000 K
1 atm

 3.56 g/L
1 bar

 3.51 g/L

400 K
1 atm

 4.01 g/L
1 bar

 3.96 g/L

360.000 K
1 atm

 4.46 g/L
1 bar

 4.40 g/L

320.000 K
1 atm

 5.02 g/L
1 bar

 4.96 g/L

300.000 K
1 atm

 5.36 g/L
1 bar

 5.29 g/L

25 °C, 1 atm

 5.366 g/L

289.774 K
1 atm

 5.55 g/L
1 bar

 5.48 g/L

285.000 K
1 atm

 5.65 g/L
1 bar

 5.57 g/L

275.000 K
1 atm

 5.86 g/L
1 bar

 5.78 g/L

270.000 K
1 atm

 5.97 g/L
1 bar

 5.89 g/L

260.000 K
1 atm

 6.20 g/L
1 bar

 6.12 g/L

240.000 K
1 atm

 6.73 g/L
1 bar

 6.64 g/L

220.000 K
1 atm

 7.37 g/L
1 bar

 7.27 g/L

200.000 K
1 atm

 8.14 g/L
1 bar

 8.03 g/L

190.000 K
1 atm

 8.59 g/L
1 bar

 8.48 g/L

180.000 K
1 atm

 9.10 g/L
1 bar

 8.98 g/L

170.000 K
1 atm

 9.68 g/L
1 bar

 9.55 g/L

165.000 K, 1 bar

 9.87 g/ml

liquid

165.000 K, 1 atm

 2.94559 g/ml

161.36 K

 2.978 g/ml

solid, 4 K

 3.78 g/cm3

Ytterbium

liquid, 1092.15 K

 6.210 g/ml

solid, 25 °C

 6.900 g/cm3

Yttrium

liquid, 1795.15 K

 4.240 g/ml

solid, 25 °C

 4.469 g/cm3

Zinc

liquid, 812.15 K

 6.427 g/ml

solid, 25 °C

 7.140 g/cm3

Zirconium

liquid, 2128.15 K

 5.800 g/ml

solid, 25 °C

 6.520 g/cm3

References    (Click the button next to a value above to see complete citation information for that entry)

Assael, Marc J., Agni E. Kalyva, Konstantinos D. Antoniadis, R. Michael Banish, Ivan Egry, Jiangtao Wu, Erhard Kaschnitz, and William A. Wakeham. "Reference Data for the Density and Viscosity of Liquid Copper and Liquid Tin." Journal of Physical and Chemical Reference Data, volume 39, number 3, 2010, pp. 033105–1 to 033105–8. doi:10.1063/1.3467496

Jensen, J. E., R. B. Stewart, W. A Tuttle, H. Brechna, and A. G. Prodell, editors. Brookhaven National Laboratory Selected Cryogenic Data Notebook. BNL 10200-R, Vol. 1, Brookhaven National Laboratory, August 1980.

Kerley, Gerald I., editor. Equations of State for Be, Ni, W, and Au. SAND2003-3784, Sandia National Laboratories, October 2003.

Kerley, Gerald I., editor. Equations of State for Titanium and Ti6A14V Alloy. SAND2003-3785, Sandia National Laboratories, October 2003.

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.

Lassner, Erik, and Wolf-Dieter Schubert. Tungsten: Properties, Chemistry, Technology of the Element, Alloys, and Chemical Compounds. New York: Kluwer Academic / Plenum Publishers, 1999.

Lide, David R., editor. CRC Handbook of Chemistry and Physics, 88th edition. Boca Raton, Florida: Taylor & Francis Group, 2008.

Madelung, Otfried, editor. Semiconductors — Basic Data, 2nd edition. Berlin: Springer–Verlag, 1996.

Šifner, O., and J. Klomfar. "Thermodynamic Properties of Xenon from the Triple Point to 800 K with Pressures up to 350 MPa." Journal of Physical and Chemical Reference Data, volume 23, number 1, 1994, pp. 63–152.

Steudel, Ralf, and Bodo Eckert. "Solid Sulfur Allotropes." pp. 1–79 in Elemental Sulfur and Sulfur-Rich Compounds I. Edited by Ralf Steudel. Berlin: Springer–Verlag, 2003. doi:10.1007/b12110

Yaws, Carl L. "Liquid Density of the Elements." Chemical Engineering, volume 114, number 12, 2007, pp. 44–46.

Yaws, Carl L. The Yaws Handbook of Physical Properties for Hydrocarbons and Chemicals. Houston, TX: Gulf Publishing Company, 2005.
